Vga Ov7670 Cmos Camera Module Lens Cmos 640x480 Sccb W/ I2c Interface

US $100

  • ShenZhen, China
  • May 27th
VGA OV7670 CMOS Camera Module Lens CMOS 640X480 SCCB W/ I2C Interface Photosensitive Array: 640 x 480; IO Voltage: 2.5V to 3.0V; Operating Power: 60mW/15fpsVGAYUV; Sleeping Mode: <20 uA; Operating Temperature: -30 to 70 deg C.; Output Format: YUV/YCbCr4:2:2 RGB565/555/444 GRB4:2:2 Raw RGB Data (8 digit); Lens Size: 1/6"; Vision Angle: 25 degree; Max. Frame Rate: 30fps VGA; Sensitivity: 1.3V / (Lux-sec); Signal to Noise Ratio: 46 dB; DynamicRange: 52 dB; Browse Mode: By row; Electronic Exposure: 1 to 510 row; Pixel Coverage: 3.6um x 3.6um; Duck Current: 12 mV/s at 6'C Application: High sensitivity for low-light operation; Low operating voltage for embedded application; Standard SCCB interface compatible with I2C interface; Raw RGB, RGB (GRB4:2:2, RGB565/555/444),YUV(4:2:2) and; YCbCr(4:2:2)output format; Support VGA, CIF and from CIF to 40 x 30 format; Vario Pixel method for sub-sampling; Auto Image Control: AEC, AGC, AWB, ABF, ABLC; Image Quality Control: Color saturation, hue, gamma, sharpness and anti-blooming; ISP includes noise reduction and defect correction; Support image scaling; Lens shading correction; Flicker 50/60Hz auto detection; Color saturation level auto adjust; Edge enhancement level auto adjust; De-noise level auto adjust   Package Included: 1 x VGA OV7670 CMOS Camera Module Lens CMOS 640X480 SCCB W/ I2C Interface Arduino Payment Shipping Refund We accept PayPal only. But we only Accept your Ebay Address,Please Make sure it's 100% right. Payment must be received in 5 business days of auction closing. Please leave note for your special request (e.g. Colors or Size) in PayPal when you pay the order. Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched. Fill your shipping info All package need to wait 30 days(US only need 7-10 days),Please take care it.Less than 30 days,we can't take a refund. If the item is defect when you receive it or you are not satisfied with it, please return it within 14 days for a replacement or money back. But the items must be back in factory condition. Please contact us and double check the return address before you return it. If is item is defective in 12 months, you can return it to us. We will send you a new replacement after receiving the defective item. On May-27-16 at 09:01:15 PDT, seller added the following information:
