Usem U7e2dcr 7 1/2hp 208-230/460v 1800rpm General Purpose Motor

US $249.99

Naperville, Illinois, United States
Jan 29th

Open on mobile:
QR code

[ USEM U7E2DCR 7 1/2HP 208-230/460V 1800RPM General Purpose Motor Please view the slideshow and the technical specifications below the description for the most accurate information on this item. We are a liquidation center so most if not all of our items have torn or missing original packaging. Please contact us if you have any questions. This is a USEM general purpose motor. It has 7 and 1/2 horse power and operates on 208-230/460 volt 3 phase power. It has an 1800 nameplate rotations per minute. The housing of the fan has a crack in it. The shaft key and screws for the electrical box cover are missing. Please see the provided slideshow for more information. Technical Specifications Item General Purpose Motor Motor Application General Application Motor Type 3-Phase Enclosure Totally Enclosed Fan-Cooled HP 7-1/2 Nameplate RPM 1800 Frame 213TC Voltage 208-230/460 Hz 60/50 Phase 3 Full Load Amps 20.6-18.8/9.4 Number of Speeds 1 Mounting Face Mounting Position Horizontal/Vertical, Shaft Down Thermal Protection None Insulation Class F Service Factor 1.25 Bearings Ball Frame Material Aluminum Max. Ambient Temp. 40 Degrees C Rotation CW/CCW Shaft Dia. 1-3/8" Shaft Length 3-3/8" Length Less Shaft 15-1/4" Overall Length 18-5/8" RPM Range 1701-1800 Standards UL Recognized, CSA Certified, CE Duty Continuous Efficiency Group Energy Efficient Nominal Efficiency 89.5% Footnotes 5,10 Green Certification or Other Recognition NEMA Premium Rated Please view all the pictures before bidding. The pictures are your best insurance to prevent hassles when attempting to return items. Shipping Weight: 151 lbs, The shipping option you are presented for this item was chosen based on appropriate options (weight, box dimensions, contents). We reserve the right to choose the method that best suits our needs, even though we may be taking a hit on shipping costs. We prefer to ship FedEX Freight. If you have a strong preference for one carrier over another, let us know at the time of payment so we can accommodate your wishes. The flat freight rate we show in our listings are based on the assumptions that the buyer is in the lower 48 states, and meets one of these criteria: 1) is a commercial site with a dock 2) is a commercial site and have the capability of taking the item off the freight trailer with your own labor. 3) are willing to pick it up yourself at the locat FedEX freight terminal (this option is open to both commercila and residential consumers). If the item is to be delivered to a residence, a smaller truck with a liftgate will be required, and these services required added fees. Please ask for a manual invoice to cover the cost of a delivery truck with a lift gate if you wish residential service. We will accept PayPal, Discover, VISA, American Express or MasterCard Credit Cards. If you wish to pick the item up at our warehouse, located in Plainfield, IL, you are welcome to do so. We will be happy to send you a manual invoice with the shipping charges removed. It is possible to return items. We have a 14 day return policy. The buyer is required to return the item to us. When it is received, it will be inspected and as long as it returns in the same condition it was sent out a full purchase price refund. If the item was our mistake then we will also reimburse the shipping costs. If it was as advertised and the buyer just changed their mind, then we will not refund the original shipping cost. If the item arrives and it damaged we would prefer to attempt to repair the item if possible. If it is not possible we will work with you to resolve the issue. The very best practice is to look at all the pictures and ask questions before bidding. Windy City Liquidation is a corporation that helps its clients dispose of unwanted inventory. Generally speaking, our customers sell through catalogs and eStores. When their catalog changes or their product offering change, they are left with inventory that can not be moved. After all, they do not have a storefront with a Clearance table!. We help our customers get the maximum value for this inventory, either through facilitating donations through a 503.C charity or selling it directly to us. We can sell on consignment, through any auction media and handle all financial transactions. We are located in Plainfield, IL.
