Us Stock 3 Nema23 Stepper Motor 270oz-in+3 Axis Board Cnc Stepper Kit

US $490

NJ, United States
Jun 9th

Open on mobile:
QR code

Good News Dear friends! Have a good News from RATTM MOTOR, we have warehouse in UK and USA, Ship from UK and USA to European Union Customers and USA, No taxes, Low shipping and international standard shipment by DHL/UPS! Delivery USA not contain Alaska and Hawaii These European Union countries are free taxes in customs: Other countries order still send from China!! Thank you for your assistance! Package include: 1 x 3 axis TB6560 Stepper Motor Driver board V type 3 x 23HS8430 stepper motor 1 x 250W 24VDC switching power supply 1 x DB25 parallel cable 1 x Fan,4pcs M4 screw English user manual for 3 axis driver board will send by email 1. 3 axis CNC controller TB6560 stepper motor driver board Products Features: CNC stepper motor driver board TB6560,the new chip TB6560AHQ of TOSHIBA, the max ouput peak current can reach to 3.5A , this driver board can drive the 2-phase or 4-phase stepper motor whose current is less than 3A. The advantages of the TB6560AHQ chip: The vibration of the motor is small and low noise: because of the 2/8/16 resolution can satisfy the different speed. Flush type low heat: The area of the chip can support itself to cool when the current is low. Supports a lot of stepper motors. The advantages in the high-speed running condition. Features: it can drive three axis,The 4th axis expansion, to facilitate your needs 4-axis machining when working Spindle relay output, easy to use software such as mach3 to control spindle start and stop. Semi-flow control functions, and effective to stop the motor when the current is reduced to a minimum. Interface with a fan, you can add fan under your choice. With 3 wire 0.8-3.5A (peak) rated output of two-phase adjustable-current bipolar stepper motor drive; Standard parallel port interface, support for MACH2, KCAM4 series software; With optical isolation and DCDC power supply isolation, the full protection of your computer parallel port and equipment; with limit switch,can connection 4 aixs limit switch Support four microstepping ——1,1/2,1/8,1/16 12—36V single switching power supply,microchips to use as a 5V power supply, stable and heat small Using RC +7414 automatic semi-flow,the current automatic reduce when stepper motor stop to down the heat Question and Answer: Q1:why other supplier’s TB6560 driver has 3.5A/3A current,but yours is 2.5A? A :TB6560 chip average output current is 2.5A,peak current is 3.5A,and can drive small than 3A stepper motor,ours 2.5A means the top average output current in real,also it is a long time security value,this is not design problem,it is according to the TB6560 chip self specification. Q2:what is the other type TB6560 driver board difference with yours? A: (1):our board with high speed isolate optical coupler can through max 40MHZ pulse,and not lose step and skewing (2): With high speed optical isolation and DCDC power supply isolation, the full protection of your computer parallel port and equipment in real,not spurious only with optical isolation (3)5V and reset use tantalum capacitors filtering wave what is better than electrolytic capacitor (4) our spindle can fit 10A replay (5) we use LM2567 microchip,low heat and enough power supply,more stable quanlity,and some other type use 78sereis common type (6) we use 5W cement resistance as feedback resistance,better heat performance and output drive wave than other board common resistance Friendly Note: It is not worthy to save small money to buy a driver board but broken mainboard or lose step and skewing when engraving. 2. Stepper Motor General Specification: Step angle accuracy: ±5%(full step,not load) Resistance accuracy: ±10% Inductance accuracy: ±20% Temperature rise: 80°C Max(rated current,2 phase on) Ambient temperature ----------—20°C~+50°C Insulation resistance:100M? Min,500VDC Insultion Strength--------500VAC for one minute Datasheet(23HS8430,8mm diameter shaft,270oz-in or 18kg.cm holding torque) Model Step Angle(°) Motor Length(mm) Rated Current(A) Phase Resistance(Ohm) Phase Inductance(mH) Holding Torque(N.cm) Detent Torque(N.cm) Rotor Inertia(g.cm2) Lead Wire(No) Motor Weight(g) 23HS0601 1.8 41 1 5.2 5.5 40 2.5 150 6 470 23HS0405 1.8 41 0.62 12 24 55 2.5 150 4 470 23HS0408 1.8 41 2 1.2 2.5 55 2.5 150 4 470 23HS4412 1.8 45 0.62 12 26 80 2.8 190 4 520 23HS4425 1.8 45 2.5 1 2.2 80 2.8 190 4 520 23HS5406 1.8 51 0.62 13 28 110 2.8 190 4 590 23HS5425 1.8 51 2.5 1.2 3.2 110 2.8 190 4 590 23HS5602 1.8 51 0.8 6.8 9.2 62 3 230 6 590 23HS6602 1.8 56 1.5 3.2 5.5 90 3.5 280 6 700 23HS6403 1.8 56 2.5 1.3 4.2 110 3.5 280 4 700 23HS6430 1.8 56 3 0.8 2.4 110 3.5 280 4 700 23HS6404 1.8 56 4.2 0.4 1.2 110 3.5 280 4 700 23HS7401 1.8 64 1 7.5 20 150 5 380 4 850 23HS7425 1.8 64 2.5 1.5 4.5 150 5 380 4 850 23HS7430 1.8 64 3 0.8 2.3 150 5 380 4 850 23HS7404 1.8 64 4.2 0.55 1.2 150 5 380 4 850 23HS8603 1.8 76 1.5 4.5 7.8 140 6 440 6 1050 23HS8425 1.8 76 2.5 1.8 6.5 180 6 440 4 1050 23HS8430 1.8 76 3 1 3.5 180 6 440 4 1050 23HS8404 1.8 76 4.2 0.6 1.8 180 6 440 4 1050 23HS1430 1.8 100 3 1.4 5.5 250 10 680 4 1250 23HS1410 1.8 100 4.2 0.8 3 250 10 680 4 1250 23HS2430 1.8 112 3 1.6 6.8 280 12 800 4 1400 23HS2410 1.8 112 4.2 0.9 3.8 280 12 800 4 1400 Note:We can manufacture products according to customer's requirements. Drawing: 3.Switching power supply 250W,Input:100-120VAC or 200-240VAC,50/60Hz,Output:24v/10,single output switching power supply Shipping Please open the package and check if there are some damages before sign, if there are some damages , please do not sign and contact us immediately We ship to USA,United Kingdom,Canada,Australia,New Zealand,Belgium,Netherlands,Luxembourg,Italy,Germany,France,San Marino,Austria, Denmark,Finland,Greece,Ireland,Guernsey Island, Jersey Island,Norway, Portugal,Spain, Sweden,Switzerland,Poland,Bulgaria,Slovenia,Slovakia,Czech Republic,Hungary, Roumania,Lithuania,Hongkong,Taiwan,Janpa,Korea,Singapore,Tailand, Malaysia,Philippines, Indonesia,if your country not in this range please contact us before you bid to check detail and confirmed for the shipping cost! we ship by DHL/UPS/EMS DHL/UPS 5-8 business days EMS 4-10 business days All items will be shipped within 1-3 business days upon receipt of payment Payment We accept paypal payment,all Paypal must be confirmed(shipping and billing address must match and correct) Payment must be made within 48hours of the auction end time Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Problem&Feedback Please give us the opportunityto resolve any problem when you have,we concern your problem and we will try our best to resolve it. We are a new member in ebay now,and need understand both of sides Pls email us before you want to leave any negative feedback Refund When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos Any reason required for all refund. Item must be in it's original condition and no physical damage. Buyer responsible for all shipping cost Contact us Welcome worldwide customer inquire and questions,we will try to do our best to feedback customer’s email within 1-2 business days,if not pls check the mail box agai Customer’s satisfaction is very important to us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RATTM MOTOR
Holding Torque	270Oz-in / 180Ncm
Model	23HS8430/3Axis TB6560 V type
Lead wire	4pcs
MPN	Does Not Apply
is_customized	Yes
Country of Manufacture	China
Type	Hybrid
Step Angle(degrees)	1.8deg
Current / Phase	3A
UPC	Does not apply
