Uni-t Ut202 Digital Clamp Meter

US $47.00

HK, Hong Kong
Jan 29th

Open on mobile:
QR code

Digital clamp meter UNI-T UT202 is a reliable and low consumption AC clamp multimeter. Digital clamp meter UNI-T UT202 measures AC and DC voltage, AC current, resistance and temperature, also performing diode check and continuity test. This digital clamp meter has overload protection. Digital Clamp Meter UNI-T UT202 Features Measuring functions: AC/DC voltage AC current Resistance Temperature Diode check Continuity test Auto ranging Data hold function Sleep mode Full icon display Low battery display Maximum value hold 28 mm maximum jaw diameter Measurement update speed 3 times/second Compact and comfortable design Compliance with safety requirements IEC61010, CAT II 600 V / CAT III 300 V Digital Clamp Meter UNI-T UT202 and UT206A Comparative Specifications Model UT202 UT206A Display LCD, max. 1999 digits 35.6 x 18 mm LCD, max. 3999 digits 37 x 18 mm DC voltage Range 200 mV / 2 V / 20 V / 200 V / 600 V 400 mV / 4 V / 40 V / 400 V / 600 V Accuracy ±(0.8%+1) Input impedance 10 M? Overload protection 600 V rms AC voltage Range 2 V / 20 V / 200 V / 600 V 4 V / 40 V / 400 V / 600 V Accuracy ±(1.2%+5) Input impedance 10 M? Overload protection 600 V rms AC current Range 2 A / 20 A / 200 A / 400 A 400 A / 1000 A Accuracy ±(1.5%+5) Overload protection 400 A rms Resistance Range 200 ? / 2 k? / 20 k? / 200 k? / 2 M? / 20 M? 400 ? / 4 k? / 40 k? / 400 k? / 4 M? / 40 M? Accuracy ±(1%+2) Input impedance 10 M? Temperature Range -40?C ~ 1000?C Accuracy ±(1%+3) ±(2%+8) Frequency Range – to 10 MHz Accuracy – ±(0.1%+3) Power supply AAA battery, 2 pcs.(3 V) 6F22 battery (9 V) Dimensions, mm 210 x 75.6 x 30 236 x 97 x 40 Weight, g 220 350 Digital Clamp Meter UNI-T UT202 Package Clamp meter UNI-T UT202 (1 pc.) Test lead (1 pc.) Point contact temperature probe (1 pc.) Carrying case (1 pc.) Batteries (1 pc.) User manual (1 pc.)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	UNI-T
Capacitance	does not measure the capacitance
Model	UT202
Frequency	up to 60 kHz
Country/Region of Manufacture	China
DC	does not measure the DC
Warranty	24
AC	up to 200 A
Jaw diameter	diameter 28 mm
Temperature	yes
DC Voltage	up to 600 V
Power	no
AC Voltage	up to 600 V
Duty cycle	no
Resistance	up to 20 MOhm
