Ultrasonic Module Distance Measuring Transducer Sensor Stable Waterproof New

US $14.62

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Recommendations For You ATmega2560-16AU Board + USB Cable Funduino 1602 HD44780 Character Display Module Breadboard 830 Point Solderless PCB MB102 AVR Programmer USB USBasp USBISP 3.3V/5V ATMEGA8 Prototyping Shield Mini Breadboard For Arduino UNO R3 PCF8591 Converter Module AD/DA Visit my eBay Store:ChipWorld Product Name: NEW Ultrasonic Module Distance Measuring Transducer Sensor Steady Waterproof More Items In Our Store,Click Here! SKU: 5046 Parsts No. : Package: Brand: Quantity: 1 Electrical properties: Electrical parameters: JSN-SR04T Operating voltage: DC 5V Quiescent current: 5mA Total current work: 30mA Acoustic emission frequency: 40khz Farthest distance: 4.5m Blind: 25cm Wiring: + 5V (positive power supply) Trig (control side) RX Echo (the receiver) TX GND (negative) Module size: 41mm * 28.5mm Resolution: about 0.5cm Angle: less than 50 degrees Working temperature: -10 ~ 70 °C Storage temperature: -20 ~ 80 °C Product Features: 1, small size, easy to use; 2, low voltage, low power consumption; 3, high accuracy; 4, strong anti-jamming; 5, integrated with wire enclosed waterproof probe, suitable for wet, harsh measurement occasions. Application: 1, Horizontal distance; 2, obstacle avoidance, automatic control; 3, the object approaches, there is a perceived 4, traffic control; 5, security, industrial control; 6, artificial intelligence, and research The basic working principle: (1) using IO port TRIG trigger location, to the high level signal of at least 10us; (2) module automatically sends 8 40KHz Fang Bo, automatic detecting whether a signal return; (3) a signal return, a high level is output through the IO port ECHO, the time duration of the high level is ultrasonic from launch to return. The test distance = (high level time * speed of sound (340M/S)) /2; This module uses the simple method, a control port with a 10US above high level, can wait for high level output at the receiving port. An output can drive the timer, when this port is low can read the timer value, this time for the location of the time, can be calculated distance. So constantly cycle test, that can achieve the measurement of the value of your mobile. For more quantity, please contact me.(My skype: ada-yu2013) The Standard shipping we provide is non-regiested mail without a tracking. We provide free shipping with tracking number when your order is over $50. If your oder is below $50 and you need tracking, please contact me. Maybe you request 2x Mega 2560 ATmega2560-16AU Board (Arduino-compatible)+Free USB Cable Funduino 2pcs DS18B20 Module DS18B20 temperature measurement sensor module 3pcs IC2272/2262 4 channel wireless remote control kits 4 key wireless remot NEW 5pcs new Breadboard 830 Point Solderless PCB Bread Board MB-102 MB102 Test DIY 9PCS NEW TEC1-12706 Thermoelectric Cooler Peltier 12V 60W 92Wmax good $ 34.0 + free shipping $ 6.0 + free shipping $ 11.5 + free shipping $18.0 +free shipping $ 28.88 + free shipping Any problem, please contact us freely 1) We accept PayPal payment ONLY. inkFrog Analytics
