Udb1108s Direct Digital Synthesis (dds) Signal Generator Module Wave 8mhz

US $3000

CN, China
Jun 3rd

Open on mobile:
QR code

Main features: 1 High Frequency resolution : 0.01Hz (2) High Frequency Accuracy : ± 20ppm ( plus or minus 20 ppm 3 Low Distortion: <1% 4 square wave 1% to 99% duty cycle precisely adjustable 5 triangular wave modulation duty cycle output two kinds of sawtooth after 6 Variable DC level control 7 External Frequency Measurement 8 The default frequency is stored , transferred functions 9.Interface 10 Dimensions : 130 ( depth ) * 102 ( W ) * 85 ( maximum height ) mm Output function signal ( main signal output ) TTL output External count input Technical indicators: Main Output waveform Sine wave , square wave , triangle wave , sawtooth Maximum output amplitude 10Vpp ( no load ) Output Impedance 50Ω ± 10% DC offset ± 2.5V ( no load ) Duty range 1% -99% ( square wave ) Display LCD1602 Output frequency range : Sine 0.01Hz-2MHz (5MHz, 8MHz) Square wave 0.01Hz-1MHz ( the valid range ) Triangle wave 0.01Hz-1MHz ( the valid range ) Sawtooth 0.01Hz ~ 1MHz ( the valid range ) Resolution 0.01Hz Frequency stability ± 1 × 10-6 Frequency error ± 5 × 10-6 Sine Wave Distortion < 1% ( reference frequency 1kHz) Triangle wave linearity ≥ 98%, 0.01Hz ~ 100kHz; ≥ 95%, 100kHz ~ 1MHz; Square wave rise and fall times <30ns TTL output TTL level ≥ 3 Vp-p Outer measurements : Frequency range : 1Hz-60MHz Signal amplitude : 0.5Vpp-20Vpp Outside the counting range :0 -4294967296 Storage and transferred : 10 set of parameters with storage and recall functions. Notice for Shipping Country Shipping time by registered air mail/e-packet Shipping time by ems/dhl/fedex express shipping United states 5-15 working days 3-7 working days (EMS recommended) Japan, South Korea 5-10 working days 3-5 working days (EMS recommended) United Kingdom, Canada, Germany, Austrian, Holland, Czech, and countries in EU 15-25 working days 5-7 working days (EMS recommended) Spain, Russian, Italy, France, Mexico, Malaysia, India, South Africa, and countries in America and Asian. 15-55 working days, (shipping time may delayed by post and customs inspection. 5-15 working days ( only EMS to Russian) Shipping list : 1.DDS signal generator 1 set 2.USB cable 1 pc 3.Q9- Clip Line 1pc 4.pdf Instructions 1pc Payment Terms1,We accept PAYPAL only. 2,We only ship to confirmed address. Please make sure your shipping address is updated. If you want to change to another address, please leave us a message immediately before it is mailed out. We will not take any responsibility for package missing because of the wrong address. Shipping Terms1,Item will be sent out within 3 working days after the payment is cleared. 2, We will ship packages by China Post flat air mail. We will offer a tracking number for free if the order total is more than 20usd. 3,We do not mail over 1mw lasers to UK, AU or any other countries ban over 1mw lasers. Over 5mw lasers are banned in some countries, please read your national laws before placing the order. We are not responsible for any consequence of the customs hold or law violation. 4,Most mail will arrive within 7-20 business days after it is sent out. The delivery time depends on factors like postal service, customs review and distance from China. If you haven’t received the item after 25 working days, please contact us. We'll investigate and solve the problem together. 5,We do not mail items to Italy and South America, Africa, etc. 6, If you need the item to be delivered urgently, please contact us for a Express shipping method like DHL/UPS etc. inkfrog terapeak
