Trimble Dcm300c Cellular Gps Modem

US $2035

  • Sandusky, Michigan, United States
  • May 26th
The rugged and robust DCM-300 modem provides wireless 3G connectivity for Connected Farm™ solutions.  It enables reliable access to Trimble® CenterPoint™ VRS™ corrections, Trimble CenterPoint™ RTX™ corrections as well as other 3rd party network RTK solutions. The modem can be used with Connected Farm for wireless data transfer between the office and field and vehicle to vehicle – allowing quicker access to data.   Compatible with most brands of equipment, the modem can also capture real-time fleet positions, public CAN messages, and fleet productivity information.   The DCM-300 is available with either EV-DO Rev A or a global ready HSDPA/UMTS network technology which support popular cellular networks such as Verizon and AT&T. ype         DCM-300G Wireless Interface: Tri-Band UMTS/HSDPA (WCDMA/FDD) 850/1900/2100 Mhz Quad-Band GSM/GPRS/EDGE 850/900/1800/1900 MHz       DCM-300C Wireless Interface: EV-DO REV A/EV-DO/CDMA 800/1900 MHz   Size 230 mm x 136.3 mm x 40 mm (9.05 in x 5.37 in x 1.57 in)   Casing Cast Aluminum   Weight 1.09kg (2.40 pounds)   Electrical   Connectors         Multi 34 Pin male positive locking       GPS Antenna SMA Jack       Cellular Antenna TNC Jack       Wi-Fi Antenna RP TNC Jack   Input Voltage 7.0-32.0 V DC   Environmental Specifications Operating Temperature -40 °C to +70 °C (-40 °F to +158 °F) Storage Temperature -40 °C to +85 °C (-40 °F to +185 °F)   Telematics GPS Positioning   Channels 12 channel; L1 C/A Code, Continuous Tracking   SBAS Support WAAS, EGNOS   Maximum Update rate 1 Hz   Horizontal Accuracy     Tracking Sensitivity –160 dBm   Acquisition Sensitivity –146 dBm   Time to Position (typical) Cold Start: 38 Seconds Warm Start: 38 Seconds After 15 Second Signal Blockage:   Certifications DCM-300G: FCC Class B Part 15, CE Mark; A-Tick mark; WEEE; RSS-210; Industry Canada; PTCRB; RoHS; SAE J1171; SAE J113-13; SAE J1455; e-Mark; IP67, IP66 DCM-300C: FCC Class B, Part 15; WEEE; RoHS; SAE; IP67, IP66
