Touch Screen Sd Reader For Arduino+mega2560 Atmega2560-16au+3.2" Tft Lcd Shield

US $320

Wuhan, Hubei, China
Jun 3rd

Open on mobile:
QR code

Touch Screen SD Reader for Arduino+Mega2560 ATmega2560-16AU+3.2" TFT LCD Shield Producct Description: Mega2560 2011: Funduino logo, desinged based on Arduino's open source schematics, 100% compatible with Arduino IDE 1.The Funduino Mega 2560 is a microcontroller board based on the ATmega2560 .It has 54 digital input/output pins (of which 14 can be used as PWM outputs), 16 analog inputs, 4 UARTs (hardware serial ports), a 16 MHz crystal oscillator, a USB connection, a power jack, an ICSP header, and a reset button. It contains everything needed to support the microcontroller; simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started. The Mega is compatible with most shields designed for the Funduino Duemilanove or Diecimila. 2.Funduino is an open-source electronics prototyping platform based on flexible, easy-to-use hardware and software. It's intended for artists, designers, hobbyists, and anyone interested in creating interactive object or environments. 3.The main reason why people choose Funduino is that they can use Funduino Language to communicate with software such as Flash and Processing etc.quickly, in this way, they can make more Multi-media interactive works. Regarding the power:Funduino Mega has two kinds of Power-supply system, USB provide power directly or depend on external power supply. The choice of power-supply is alternative. If you choose external power supply, you can use AC-to-DC Adapter or Batteries, the voltage range is 6V-12V, but if the voltage smaller than 6V, the voltage of I/O Interface may cannot reach 5V, so it become unstable. And if the voltage is more than 12V, the voltage stabilizer will refer to overheat protection, then it will damage the Funduino Mega. In this way, the recommended operation voltage is 6.5V-12V, power source is 7.5V or 9V 3.2" TFT LCD Screen Module: TFT01-3.2 TFT01_3.2_D is a TFT LCD Screen Module , 40pins interface , not just a LCD break but include the Touch , SD card and Flash design. So it’s a powerful extension module for your project. The LCD in the TFT01 is 240374PQ . It’s a 65K color , 320*240 (resolution),3.2 inch TFT LCD screen.The LCD has a wide viewing angle , the contrast is also very suitable. The Screen include a controller SSD1289, it’s a support 16bit data interface , easy to drive by many MCU like STM32 ,AVR and 8051. The TFT01_3.2 layout a 40 pins interface for your project , the interface include LCD bus, SD card bus, Touch screen bus and the Flash bus. And we have TFT01 Arduino shield and TFT01 Arduino MEGA shield(recommand), you can directly plug the TFT01 LCD module in the shield and stand on the Arduino board. Touch Pen Get from here. There is a very excellent and powerful enhance Graphic library which written by Henning Karlsen Fully compatible with TFT01 LCD module and TFT01 Arduino Shield. The library is quite a bit faster, and also include more functions. Please reference post from here. Note: TFT01_3.2 is only 16bit mode. LCD TFT01 Arduino Mega Shield v1.2 The TFT01 LCD module is work in 3.3V voltage level and it's not compatible with Arduino MEGA pins , so we make a shield for Arduino MEGA. Now user can directly plug the TFT01 in the shield and stand on the Arduino MEGA board. The TFT01 MEGA shield V1.0 supports both 16 bit mode. Because of Mega board have enough pins for using SD card and Touch function at the same time. Package: 1x mega2560 2011 ( funduino brand) 1x 3.2" lcd display board 1x 3.2" display board shield 1x usb cable Payment Method: PalPay preferred Shipping Method We ship to USA by e-packet delivery shipping method, and we ship to rest of the word by registered China Post Air Mail, to most of countries, it taks 10-15 business days to arrive if no shipping delay is incured. but to some countries in South America, Africa and East Aian countries, it can take longer time, as long as 40-60 days. If you need items urgent, we can also ship by express shipping such as Fedex, DHL, Aramex and EMS. EMS is still very slow. we will choose Fedex for express shipping without special instruction from our customers, because we have business corporation with Fedex company which provide very much fast service. Shipping time Country Shipping time by Registered Air Mail or E-packet delivery Shipping time by FedEx/DHL/TNT/EMS United States 5-15 business days 3-5 business days(Fedex recomended) Japan, South Korea 5-10 business days 3-5 business days (Fedex recomended) United Kingdom, Canada, Germany, Austria, Holland, Czech, EU 15-25 business days 4-6 business days(Fedex recomended) Spain, Russia, Italy, France, Mexico, Indonesia, Malaysia, India, South Africa, American & Asian countries 15-55 business days 5-15 business days(Fedex recomended) Feedback & DSR Please leave us positive feedback and 5-star DSR if you find our products and our service is of nice quality. If you think shipping speed is slow, contact us to let us know, we reimburse you shipping charge. If you have any problems with the product, please contact us also to solve it. If you just don't like our products, please just send back to us for new replacement or full refund. Case & Return Please don't easily open an ebay or Paypal case or return case with us, tell us what is the problem, we will solve any problems and cover your own rights.
