Total Power : Switched Power Supply Tp95a Tpfb-50-4-a 50w Multiple Output Power

US $109.00

  • Tampa, Florida, United States
  • Jan 31st
Open on mobile:
QR code
Total Power Europe BV Kloosterstraat 5 4901 HR Oosterhout Nederland Tel: +31 (0) 162 570087 Fax: +31 (0) 162 523274 E-mail: sales@totalpower.org Total Power Europe BV Specialist in Power Conversion Time protected peak output power of more than 2 times the nominal rated value 50W POWER SUPPLY FOR COFFEE DISPENSERS  Product Highlights: 85 -264 Vac universal input range. High peak output power ( 110W ). 4 output voltages. Fully overload protected by means of a fast acting high- and a time delayed low trip level. High efficiency. Fully functional under no load conditions. Over Voltage Protection on the main output. 100% final test and burn-in. Full compliance to international EMI / RFI standards. UL and CE marked.  Mechanical Performance:  The power supply is built as an open frame unit with  a special shaped Printed Circuit Board. By means of  cut-outs in the plastic dispenser housing the unit is  placed and fixated in vertical position. The power  supply is capable to operate with limited air  convection.  Dimensions:  PCB - 100 x 125 mm  Max. height - 50 mm Application: This model is specifically designed to supply a special compact size coffee dispenser for the professional market where the application is characterised by 24 hours a day operation time at elevated temperature and high power demands for only a short period of time. These peak load current demands caused by motors, valves and electromagnetic relays need to be thoroughly appreciated in order to achieve an optimum high reliability, low cost and small size. Model description: The power supply converter circuitry is based on the fly-back principle being a cost effective topology providing a high efficiency and very compact dimensions. In this particular application the main output is used to supply the peltier element applied in the system to cool the coffee abstract. The second ( 5V ) output is used to supply the digital control electronics while the third and fourth output supplies relays, valves, motors and the coffee dosing coils. TPFB-50-4-A Application note 95A
