TinyG CNC Controller Board v8, US $109.00 – Picture 0
TinyG CNC Controller Board v8, US $109.00 – Picture 0

Tinyg Cnc Controller Board V8

US $109.00

  • Colorado Springs, Colorado, United States
  • Feb 21st
Open on mobile:
QR code
Product Details The TinyG is a hardware and firmware project that is a multiple-axis motion control system. It is designed for small CNC applications and other applications that require highly controllable motion control. TinyG is meant to be a complete embedded solution for small/medium motor control. This CNC controller was pulled from a working machine and is like new! Upgraded to the latest firmware. Up to 6 axis (XYZ + ABC rotational axes) control with drivers for 4 axes on board. Working Voltage: 12-30VDC (24 is Ideal) Stepper drivers can deliver up to 2.5 amp per winding. Selectable micro-stepping up to 1/8. Acceleration planning performed using constant jerk motion equations (3rd order S curves) for very smooth and fast motion transitions for lines and arcs Full, integrated motion control system with embedded microcontroller (Atmel ATxmega192) and 4 stepper motor drivers (TI DRV8818) integrated on a ~4 inch square board Accepts Gcode from USB port and interprets it locally on the board Easily upgraded by the user with a few commands through the USB port. RoHS compliant. TinyG is open source. The documentation can be found here. Wiki Source Code
