Texas Instruments 15am Motor Protector/thermal Cut-out 70°c Model 011a034a

US $18.50

roma, Italy
Jan 29th

Open on mobile:
QR code

Product Bulletin 15AM Motor Protector/Thermal Cut-out As world market leader in appliance motor protection Texas Instruments builds the 15AM motor protector to meet almost any application in this field. The 15AM is designed to provide locked rotor and overload protection in a wide variety of motors for industrial and domestic appliances. The 15AM is the leader in the European AC motor protection market. Design & operating principles In the 15AM design the nickel plated shell holds and protects the inner components against varnish penetration and mechanical forces. The heart of the device is the calibrated Klixon™ bimetal disc, responding to current and temperature changes. It is supported by a slug and a contact welded on the disc. The fixed contact is placed on the opposite nickelzinc coated plated steel shell, separated by a coated gasket for insulating and sealing. The 15AM can be supplied as a basic device with leads and other integrated quick connectors or automated connection systems. Customized lead configurations are available on request. The 15AM can be fitted in the best possible mounting location in combination with the optimum assembly operation. As the 15AM is a metal device it may be necessary to insulate the device from other conductive parts, an insulating sleeve is available on request. The operating principle of the 15AM is both simple and effective. A current flows through the resistive Klixon™ bimetal disc. When a fault condition occurs, the increased current and shell temperature heats up the bimetal disc which opens the contacts. As the device cools down to a safe temperature, the contacts will automatically reset. Applications The 15AM operates as an incorporated thermal sensitive protector in electric motors for pumps, washing machines, dish washers, dryers and in several other applications like vacuum cleaners, fans, battery chargers, transformers for lighting (EN 61558) and microwave ovens. Key Benefits • Texas Instruments Engineering knowledge base • Provides mounting flexibility • European supply • Competitive price • Local Engineering

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	texas instruments
MPN	texas instruments 15AM 011A034A Cut-out 70°C
Model	15AM 011A034A
