Telmecanique Xckmr54d1h29 Limit Switch

US $150.00

Maryville, Tennessee, United States
Jun 9th

Open on mobile:
QR code

OPEN BOX NOT USED>Switch actuation By any moving part Electrical connection Screw-clamp terminals, clamping capacity: 1 x 0.5...2 x 2.5 mm? Contacts insulation form Zb Number of steps 5 electrical positions Contact block per direction (control circuit) 1 per direction Positive opening With Positive opening minimum torque 6.64 lbf.in (0.75 N.m) Minimum torque for tripping 4.42 lbf.in (0.5 N.m) Minimum actuation speed 6 m/min Maximum actuation speed 4.92 ft/s (1.5 m/s) actuation point on the rod between 65 and 95 mm Maximum displacement angle 180 ° -180 ° Contact code designation Q150, DC-13 (Ue = 125 V, Ie = 0.55 A) conforming to EN/IEC 60947-5-1 appendix A A300, AC-15 (Ue = 240 V, Ie = 3 A) , Ithe = 10 A conforming to EN/IEC 60947-5-1 appendix A [Ui] rated insulation voltage 300 V conforming to CSA C22.2 No 14 500 V degree of pollution 3 conforming to EN/IEC 60947-1 300 V conforming to UL 508 Resistance across terminals <= 25 MOhm conforming to IEC 60255-7 category 3 [Uimp] rated impulse withstand voltage 6 kV conforming to EN/IEC 60947-1 6 kV conforming to IEC 60664 Short circuit protection 10 A by gG cartridge fuse Mechanical durability 2000000 cycles Width 7.87 in (200 mm) Height 4.65 in (118 mm) Depth 2.32 in (59 mm) Product weight 1.21 lb(US) (0.55 kg) Terminals description ISO n°1 (11-12)NC (21-22)NC Environment Shock resistance 50 gn conforming to EN/IEC 60068-2-27 Vibration resistance 25 gn (f = 10...500 Hz) conforming to EN/IEC 60068-2-6 IP degree of protection IP66 conforming to EN/IEC 60529 IK degree of protection IK07 conforming to EN 50102 Class of protection against electric shock Class I conforming to IEC 60536 Ambient air temperature for operation -13...158 °F (-25...70 °C) Ambient air temperature for storage -40...185 °F (-40...85 °C) Protective treatment TC Product certifications CCC CE CSA UL Standards EN/IEC 60947-5-1 UL 508 CSA C22.2 No 14

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Telemecanique
Country/Region of Manufacture	Indonesia
Model	XCKMR54D1H29
