Tektronix Type 109 Pulse Generator & 017-067 Charging Network

US $74.99

Greenwood, Mississippi, United States
Mar 14th

Open on mobile:
QR code

Electrolytic capacitors often fail, especially those of the Tantalum composition/variety. All tantalum variety electrolytic capacitors should be replaced with their indicated values in the service manual. Smaller electrolytic capacitors should be replaced with their equivalent in the service manual, paying close attention to working voltage and capacity. The larger value capacitors, such as the filtering capacitors in Tektronix TM 500 mainframes, need to be checked for higher than normal ESR versus the corresponding data sheetвЂ™s indicated values and filtering capacity under load (ripple voltage/current) against the corresponding The Tektronix Type 109 Pulse Generator and 017-067 Charging Network is an auction item available for purchase. This product is a low repetition high rise-time pulse generator with a 50-ohm charging network. The shipping of this item is insured and can be sent through USPS Priority Mail, UPS, or FedEx. The dimensions of this item are 12x16x9" and 11lbs, 8oz. It is important to note that there are additional terms and conditions to be aware of before purchasing this item. By bidding or winning this auction, you are agreeing to these terms. The item is being sold AS-IS, with no refunds or exchanges. Please bid accordingly. The only items included for sale in this auction are the ones specifically listed. There may be other equipment present for the purpose of displaying basic functionality, but they are not for sale. In order to ensure proper operation of this equipment, it should be maintained with the proper servicing and calibration per manufacturer specification. It is highly recommended to have the power supplies checked in accordance with the owner's or service manual for all vintage test equipment, especially for Tektronix equipment. Cleaning all switches and potentiometers in accordance with the service manual is also important. This is vintage used test equipment that has been tested for turn-on only. Due to the age, it is possible that functionality may be lost during transport. It is not possible to check for 100% functionality without a complete calibration, which has not been performed. These products are not refurbished, and absolute calibration is NOT guaranteed or warrantied. It is important to check the pictures for any cosmetic or physical damage. These pictures represent the actual items available for bid or auction. As a bidder or auction winner, you may know more about the item than the seller. The seller does not claim to have expert knowledge of the equipment.
