Tektronix 608 X-y Analog Crt Monitor

US $200.00

  • East Providence, Rhode Island, United States
  • Mar 2nd
Standard Description Description Tektronix 608 X-Y Analog CRT Monitor The 608 Monitor is a solid-state instrument with excellent resolution, providing accurate displays of information from the X, Y, and Z signal inputs. Vertical and horizontal signals to be displayed on the CRT are supplied to the Deflection Amplifiers through the appropriate X and Y INPUT connectors. The Deflection Amplifiers process the input signals and provide push-pull outputs to drive the deflection plates of the CRT. Both Deflection Amplifiers contain position and gain controls. The Z-Axis Amplifier controls the display intensity by providing a voitage to drive the CRT controi grid. input signals are applied to the Z INPUT connector. The Dynamic Focus circuit provides focus correction for the display when the CRT beam is deflected from the CRT center: Thus, by varying the voltage to the CRT focus element, the Dynamic Focus circuit compensates for geometric defocusing. The High-Voltage and Low-Voltage Power Supplies provide all the voltages necessary for operation of this instrument. The item is in good condition, tested and working. Instruction Manual available here. Shipping Weight (lbs.): 30 Shipping Dimensions (in.): 25 x 25 x 13 Click Here for Terms and Conditions of Sale
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Tektronix
Type Analog
Model 608
