Tcp/ip One Door 20k Users 100k Event Power Supply Iron Box Net Access Controller

US $75.90

???, ???, China
Jan 30th

Open on mobile:
QR code

TCP/IP One Door 20K Users 100K Event Power Supply Iron Box Net Access Controller + 1PC 1PC Specifications: Preferences Single Door/Bidirectional Controller 2-Door/Bidirectional Controller 4-Door/Unidirectional Controller Model WG2001 WG2001.NET WG2002 WG2002.NET WG2004 WG2004.NET Software Download Download Software +Wiring diagram+Software Introduction link below: Double click "setup.exe".After installation,username:ABC,Password:123 Communications RS485 TCP/IP 10M/100M Self-adaptive RS485 TCP/IP 10M/100M Self-adaptive RS485 TCP/IP 10M/100M Self-adaptive Description One door,Card enter, Card or button exit 2 doors,Card enter, Card or button exit 4 doors,Card enter,Button exit PCB Dimensions 160mm *106mm 160mm *106mm 218mm*106mm Iron Box Dim 273mm*228mm*65mm Power Supplier 12VDC 4-7A Current <100mA Acceptable Card Readers' Format Wiegand 26bit or 34bit(optional by hardware switch,default is 26bit) Extensible Card Readers 2 4 4 Door(s) for control 1 2 4 Delay 1-600 seconds adjustable Max units online N*256 Unlimited N*256 Unlimited N*256 Unlimited Note:"N" means quantity of Com ports or RS485 Hub's ports Working Temperature -40 ~70 Centigrade Working Moisture 10-90%RH Max Users Quantity 20,000 Event records quantity 100,000 Power off Protection High speed flash memory,keep data safe without power Max Distance from Reader to Controller Max to 100M Max Distance from Controller to PC RS485:Max to 1,200M,Reliable value 1,000M,can be extended up to 3000 M by RS485 relay. TCP/IP:According to the network coverage Accessories PCB*1pcs,CD*1pcs,Manual*1pcs,Certificate*1pcs,Carton * 1pcs Alarm when: Door unclosed overtime, unlawful entry or being Threatened yes yes yes Fire protection & Alarm Trigger If theft or fire occurs,the software can alarm by PC's speaker. If the controller contact to "alarm external module",it can also drive the alarm Siren, Hold the door open/closed by software yes yes yes Remote open by software yes yes yes Programmable I nterrelation of doors' condition (open/closed) yes yes Note:you can setup the interrelation between the doors Arbitrarily, such as "only when door A is open &door B is closed,Door C can be openned" Anti go back convertly, Anti followed yes yes Note:This function means if a card has already exited,it can not exit again without enter. Multi-card open yes yes yes Note:A door can be openned only when 2 or more cards are read (multiple persons are present). This function maybe useful for very important place. programmable time of hold open yes yes yes Note:can setup the door hold open at a specified time, maybe useful during the period of going to work every morning Electrical Map yes yes yes Note:Can easily know your doors' condition vividly from the software. Urgently close Both enter&exit yes yes yes Note:The door(s) can be hold closed, refuses both enter and exit in case of theft or other accident occurs. Initial Card yes yes yes Note:If Initial Cards was activated,Only after Initial card is read,Other user cards can be available. validate from both side yes yes yes Note:Door can be set to openned only when card reading from both outside and inside of the door. Extensible pin code RFID reader (card+pin code/ super password) yes yes yes Note:Door can be set to openned only when both card reading and pin code pressed. Software screenshot Please download software from the link below: http://xiaolong.dbankcloud.com/wg2000ENGLISH.rar Shipping Detail: 1.We only ship to your confirmed address,Please make sure your shipping address is correct before purchase 2.If you choose the Economy Shipping.The delivery time is normally 15-45 days. Please be patient.If you are urgent.Maybe you can choose the Expedited Shipping, That is Express . Such as DHL/Fedex. 3.If your address is Brazil,please let me know your Tax number.Thanks! Feedback: 1.Offering the best quality products and service are our main mission, and this is depending on your feedback , so please give us timely advice. 2.If you are satisfied with our products and service,please kindly help leave positive feedback and we will do the same for you: We care about all our customers very much, and will try solving any unexpected problem eventually.If you are not satisfied with our products.please feel free to contact us in time,we will try our best to settle the problem until you are happy!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	KO-WG2001
Country/Region of Manufacture	China
