Swagelok # Ss-65tsc16 , 1" Ss 3-piece 60 Series Ball Valve, Clamp Fitting

US $95.00

  • Los Angeles, California, United States
  • Jan 30th
SWAGELOK # SS-65TSC16 , 1" SS 3-PIECE 60 SERIES BALL VALVE, CLAMP FITTING WE HAVE MANY OF THESE VALVES , SOME END WITH THE SUFFIX EP, BUT MOST DONT SPECIFICATION SUMMARY Flow Pattern Straight (2-way) Service Class General Size 1 in. Nominal - 65 Series Valve Material Stainless Steel End Connection 1 Size 1 in End Connection 1 Type ISO Sanitary End Connection 2 Size 1 in End Connection 2 Type ISO Sanitary Handle Color Black Handle Style Lever Approval No Approval Ball/Stem Material Stainless Steel Cleaning Swagelok® Standard cleaning SC-10 Fastener Material 316 Stainless Steel Flange Seal Material Fluorocarbon FKM ID Tag No Laser Etch No Low Dead Space Insert No Lubricant Dow111 and WL8 Packing Reinforced PTFE Seat Material Reinforced PTFE Seat Spring Material 316 Stainless Steel Stem Bearing Material Alloy X750 Testing Testing according to WS-22 Max Temperature Pressure Rating 450°F @ 100 PSIG /232°C @ 6.8 BAR Room Temperature Pressure Rating 300 PSIG @ 100°F /20.6 @ BAR 37°C ITEM # i1 SHIPPING TO U.S.A.
