Sv 32 Apc Verticle Maching Center

US $27,900.00

  • Tulsa, Oklahoma, United States
  • Jan 30th
2003 SV 32 CNC Milling machine w/ APC. Loaded with options.!! See in Tulsa, Ok. Call 918-894-8001. Sold As Is Where Is. USED JOHNFORD MODEL SV-32 APC VERTICAL MACHINING CENTER WITH AUTOMATIC PALLET CHANGER MACHINE SERIAL NUMBER MB2312 Year sold new 2003 Specifications: X Axis Travel................................................................................................ Y Axis Travel................................................................................................ Z Axis Travel................................................................................................ Table To Spindle........................................................................................... Table Working Surface................................................................................. Maximum Table Load................................................................................... Spindle Motor............................................................................................... SpindleSpeeds............................................................................................. Spindle Torque.............................................................................................. 31.5" 20" 24" 5.7" Min/ 29.7" Max. 40" x 20" 1760 lbs. 15 HP High torque 5-10,000RPM 170 ft/lbs @ 455 RPM Cat 40 24 Tools Bi-directional-random 1.3 sec tool to tool 3" w/adjacent tools 22 Lbs. 12" 1181, 1181, 787 IPM 50 gallons 12,100lbs. Spindle Taper................................................................................................ Automatic Tool Changer.............................................................................. Tool Selection.............................................................................................. Tool Change Time....................................................................................... Maximum Tool Diameter............................................................................. Maximum Tool Weight................................................................................ Maximum Tool Length................................................................................. Rapid Traverse Rate X,Y,Z.......................................................................... Coolant Tank Capacity................................................................................. MachineWeightw/outAPC........................................................................ Machine Power .............................................................................208/220 Volts 3 Phase, 75 Amps Automatic Pallet Changer : Table Work Surface...................................................................................... 33.8" x 17.7" Maximum Table Load Capacity................................................................... 750 Lbs. Pallet Surface................................................................................................ Milled/T-Slotted Number of T-Slots........................................................................................ 5 x 18MM Pallet Change Time....................................................................................... 15 Seconds Equipped with: Fanuc 16MC CNC Control 10,000 RPM Spindle Lathe Type Chip Conveyor Automatic Pallet Changer with Pallets RISC and DATA Server Custom Macro B Coolant Thru The Spindle 300 PSI Spindle Chiller Rigid tapping New X axis drive motor within last 6 months New X axis way Covers New Manual Pulse Generator (Nothing wrong with the old one, just looked worn) New Ball screws within the last 6 monthsPosted with eBay Mobile
