Studio Technologies 5150 Video Generator Module 720/1080

US $940

  • Los Angeles, California, United States
  • May 31st
FOR SALE IS A VIDEO GENERATOR MODULE! MANUFACTURER: STUDIO TECHNOLOGIES  MODEL: 5150  SPECIFICATIONS: SDI Compatibility, Supported Formats and Rates: HD-SDI per SMPTE ST 292: 2011: 720p: 50, 59.94, 60 1080i: 50, 59.94, 60 1080p: 23.98, 24, 25, 29.97, 30 1080psf: 23.98, 24, 25 3G-SDI Level A per SMPTE ST 424: 2006 and ST 425:2011: 1080p: 50, 59.94, 60 SD-SDI per SMPTE ST 259: 2008: Not supported Coaxial (BNC) SDI Input and Output: Type: unbalanced Impedance: 75 ohms Level: 800 mV p-p, nominal Optical Input (optional): Compliance: SMPTE ST 297:2006 (as applicable) Fiber Type: single mode Wavelengths Supported: 1250 to 1650 nm Receive Sensitivity: -17 dBm, nominal @ 2.97 Gb/s Maximum Input Power: -3 dBm, nominal Optical Output (optional): Compliance: SMPTE ST 297:2006 (as applicable) Fiber Type: single mode Wavelength: 1310 nm (FP laser) or CWDM (DFB laser), as per order Launch Power: -3 dBm, nominal Typical Fiber Interconnect Length: 10 km minimum GPI: active low, "pulled up" to 3.3 volts DC using 5 k ohm resistor; activates on closure to common (applies to Model 5150 modules with serial numbers 00251 and later) GPO: active high, 3.3 volts DC with series resistance of 150 ohm; short circuit current of approximately 22 milliamperes in reference to common (applies to Model 5150 modules with serial numbers 00251 and later) Remote Control Data Interface: RS-485 115.2 Kb/s, 8-1-N; compatible with Studio Technologies' Model 5190Remote Access Module Connectors: Coaxial SDI Input and Output: BNC, 3G-SDI optimized, gold plating on center pin, per IEC 61169-8 Annex A Optical Module: MSA-compliant SFP DC Input/Data: 1, 4-position male header; refer to Appendix B in the User Guide for mating connector details GPI/GPO: 1, 3-position male header (applies to modules with serial numbers 00251 and later); refer to Appendix B in the User Guide for mating connector details Power Requirement: 12 volts DC nominal, 400 mA max; acceptable range 10-18 volts DC, 480 mA max at 10volts Dimensions (Overall): 3.75 inches wide (9.5 cm) 1.69 inches high (4.3 cm) 2.30 inches deep (5.8 cm) Mounting: requires custom implementation; no mounting method provided; refer to Appendix C in the User Guide for details ITEM IS USED DOES NOT COME WITH POWER SUPPLY OR OTHER ACCESSORIES FREE DOMESTIC SHIPPING! ITEM 124 SERIAL # 189
