Stepper Motor Controller & Driver Ii (2 Control Modes)

US $890

Guangzhou, Guangdong Province, China
Jan 29th

Open on mobile:
QR code

Note: This is an online auction. If you want to get the item immediately or in wholesale lots, please click here to Buy It Now item. Stepper Motor Control & Driver Board II (4A) This item contain: one Board II + one 4-pin cable Profile This stepper motor control&drive board has two control modes switched by jumper JP1: 1. By pulse and signals (JP1 Off) Input pulse and signals to control the motor run, stop and direction. 2. By buttons (JP1 On) There are 3 buttons marked "INC""DEC""FUN" on the board, you can press them to control stepper motor accelerate/decelerate, CW/CCW, stop etc. For the board's flexibility (it can work even without pulse), so it suit for experiment demo, prototype making, student training, people DIY etc. Functions And Features: 1. Matching motors: 6 wires stepper motor, 2-phase or 4-phase, amperage<4A. 2. Need two power supplies: 5VDC for the board; 3-40VDC for stepper motor (corresponding to your motor votage). 3. Motor speed can be adjusted and memorized. Operation Menu: 1. Terminal Block Connection A: A+ B: A- C: B+ D: B- COM: Common VCC, GND: 3-40VDC power supply 2. Pins Connection & Jumpers setting a. Control by pulse and signals (JP1 Off) +5V, GND1: 5VDC power supply CP: Input pulse DIR: Direction signal GND2: Empty b. Control by buttons (JP1 On) +5V, GND1: 5VDC power supply CP, DIR, GND2: Empty JP2 On INC: CW run DEC: CCW run FUN: Stop JP2 Off INC: Acceleration (One time of pressure, one speed level upgraded. You will find it turn faster apparently after several times of pressure.) DEC: Deceleration (Though CCW run, you will find it slow down apparently after several times of pressure.) FUN: Speed memory (Suggest you can mount-on JP2 after speed adjustment, then it be memorized even power off.) Note: 1. What you bid does not include the motor, the picture just to state how to hook. 2. Please turn off power supply before you mount-on or remove the jumpers. Any other question, please feel free to contact me. I will reply your message in 24 hours. Shipping Nomally, The delivery time of airmail is 7-15 business days. EMS (3-5 business days) and DHL / UPS (2-4 business days) is available, but the shipping fees are higher. Please contact us first. Payment We accept Paypal only. Warranty 7 days warranty. Feedback If you are not satisfy the item you received, please contact me first. Please don't leave negative (neutral) feedback without communication. More Products Board I (2A) Board II (4A) PC Control Programmer Control eBay Cross Border Trade powered by MerchantRun GlobalLink
