Spectrum Analyzer Analyser 150k-1ghz With Tracking Generator 110-220v At5011a

US $799.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea, Malaysia, Thailand, Indonesia, Philippine. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you bid. Features * Frequency range: 0.15 ~ 1050MHz * 4 half figures (center frequency, 0.1MHz Resolution) * -100 ~ +13 dbm amplitude range, 20KHz, 400KHz IF filter bandwidth and 4KHz video * Tracking generator * Output range: +0 ~-50dBm (50Ohm) Function >>> CATV and communications machine inspection: with the impedance converter (50 Ohm converter to 75 Ohm) >>>GSM, CDMA mobile phone repair >>>Point frequency mode and Sweep mode >>>Frequency Measurement Extension * With the Frequency Expander AT5000-F1, the measure frequency can expand to 2000MHz (qualitative measurement), the measuring range is 1050 MHz ~ 2050 MHz. But it can only be used for input channel expansion, not suitable to the Tracking Generator. * With the Frequency Expander AT5000-F2, the measure frequency can expand to 3000MHz (qualitative measurement), the measuring range is 2050 MHz ~ 3050 MHz. But it can only be used for input channel expansion, not suitable to the Tracking Generator. >>>Electromagnetic Compatibility Test (EMC) * Conducted interference test: With the AT-166 conducted interference interface (only a little stock, not produced now) * Radiated interference test: With the AZ-530-E electric field monopole probe * Internal Circuit Interference test: With the AZ-530-M magnetic field probe * Internal circuit Checking and repairing Test: With the AZ-530-H high-impedance probe Specifications Frequency Range: 0.15 ~ 1050MHz Center frequency display accuracy: plus or minus 2% x spectral width of +5 x 10^-3 x center frequency +100 KHz Tag accuracy: plus or minus 0.1% bandwidth +100 HKz Frequency Display Resolution: 100KHz (4 1/2 -digit LED) Sweep width: 100KHz / cell ~ 100MHz / 125 block grid and 0Hz / cell (0 scan), accuracy: plus or minus 10% Frequency stability: better than 150KHz / hour IF Bandwidth (-3dB): 20KHz (plus or minus 50%); 400KHz + (0, -40%), video filter (pass); 4KHz Scan Rate: 43Hz Margin Range: -100 ~ +13 dBm Screen display range: 80dB (10dB / cell) Reference Level:-27dB at 500MHz Department The average noise level:-90dBm (20KHz bandwidth, typical dBm) Distortion: 2 3rd harmonic <-55dBc 3-order intermodulation:-70dBc Sensitivity: Better than-90dBm Log scale fidelity: plus or minus 2dB (without attenuator), 500MHz Input / Output Impedance: 50Ohm Socket: N (F) connector Attenuator: 0 ~ 40dB (4 x 10dB step) Input attenuator accuracy: plus or minus 1dB/10dB Maximum input level: +10 dBm, plus or minus 25VDC (Attenuator 0dB), +20 dBm (40dB attenuator) Others Power: 200VAC/110 VAC plus or minus 10%, 50Hz ~ 60Hz Track calibration: adjustment in the panel (TR) Power: 20W plus or minus 20% Protection: Security 1 (IEC1010-1) Size: 285 (W) x 125 (H) x 380 (D) mm Net Weight: 9.5 kg,the packaged weight can be up to 11Kg. Tracking generator Output Frequency Range: 0.15MHz ~ 1050MHz Output Level Range: -50 ~ +1 dBm (10dB variable step adjustment) Output attenuator: 0 ~ 40dB (4 x 10dB) Accuracy (attenuator): plus or minus 1dB Output impedance: 50Ohm (BNC) Frequency range: 0.15 ~ 1050MHz Frequency response: plus or minus 1.5dB Radio frequency interference (RFI): <20dB

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	AT5011A
Analyzer Type	Spectrum Analyzers
MPN	AT5011A
Unit Type	Complete Systems & Mainframes
Country of Manufacture	China
