Sokkia Set530r Reflectorless Total Station

US $3,580.00

  • Riga, Latvia
  • Jan 30th
All instruments before sale have been checked and calibrated. Specifications Telescope Magnification SET530R: 30x Angle Measurement Photoelectrical absolute rotary encoder scanning Display Resolution (selectable) H & V 1"/5",0.2/1mg, 0.005/0.02mil Accuracy (ISO 12857-2 1997) H & V SET530R: 5" Compensator Automatic dual-axis compensator Distance Measurement Modulated laser, phase comparison method with red laser diode, coaxial optics Maximum Measuring range - Reflectorless1 SET530R: 150m (490ft.) Maximum Measuring range - Reflective Sheet RS90N-K SET530R: 500m (1,640ft.) Maximum Measuring range - One AP01Prism2 SET530R: 5,000m (16,400ft.) Accuracy - Reflectorless1 SET530R: 0.3 to 200m (1 to 490ft.): ±(3+2ppmxD)mm; Over 100 to 150m (over 320 to 490ft.): ±(5+10ppmxD)mm Accuracy - Prism/sheet Glass Prism: ±(2 + 2ppm x D)mm, Reflective Sheet: ±(3 +2ppm x D)mm Data Storage - Internal Memory Approx. 10,000 points Weight w/ handle and battery 5.4kg (12lb.)
