Single Ended Shear Beam Load Cell 5k 5,000 Pound Capacity Sealed

US $25.00

  • Brookville, Indiana, United States
  • Jan 29th
Open on mobile:
QR code
Used 5,000 pound capacity single ended shear beam load cell.  Tested in our press at 2.00 mV/V at 5K pounds.  No grounds or drifting seen.  Guaranteed not DOA. Input resistance:  1100 ohms Output resistance:  1000 ohms Wiring:  E+ = Red, E- = Black, S+ = Green, S- = White Stainless steel body, welded construction, Teflon cable lead.  IP68 sealed (hermetic, metal to glass seal).  Cable lead is around 1' long due to being cut.  Can be spliced or wire grip removed and new cable soldered on. Load cell body is roughly 1 3/16" x 1 3/16" x 5 1/4" long.  Wire grommet housing is about 1 3/4" long.  The rear two mounting bolt holes are 1" apart and are made for 1/2" bolts.  The cantilever end bolt mount is 1/2" - 20 UNF and is 3" from the middle bolt hole.  There is an approximate 0.030" step between the two mounting holes and the cantilever mount. Shipping to the continental USA only.
