Sheldon R13, R15, & R17 Precision Lathes Instruction Manual *1260, US $1100 – Picture 0
Sheldon R13, R15, & R17 Precision Lathes Instruction Manual *1260, US $1100 – Picture 0

Sheldon R13, R15, & R17 Precision Lathes Instruction Manual *1260

US $1100

  • Goddard, Kansas, United States
  • Jun 2nd
Open on mobile:
QR code
 Sheldon R13, R15, & R17 Precision Lathes  Instruction  Manual For models: Sheldon No.'s R13, R15, R17 Description: This is an Instruction Manual for the Sheldon No.'s R13, R15, & R17 Precision Lathes. It has sections on Lathe Installation, Lubrication, Operation, Adjustments, Belts, Troubleshooting List, and Wiring Diagrams. It has 24 pages.  To inspect the quality of the manual, and to view select pages,  please click on the gallery images above to enlarge. Includes sections on: Lathe Installation Operating Procedures Lubrication Selection of Threads & Feeds Apron & Carriage Sheldon Cross Slide Telescopic Taper Attachment Adjusting the Headstock Spindle Bearings Motor Drive Belts Lead Screw and Feed Rod End Play Dissassembly of Lead Screw and Feed Rod Compound and Cross Slide Gibs Wiring Diagrams Electrical Troubleshooting (General) Number of pages: Approx 24 Condition of original:   Very Good Publication date: N/A Publication No.:  N/A Added Notes:   Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice. About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop. Questions? Email: eugene@fabersurplus.com Phone: 316-210-4079 after 11:00 am Central Time Ships USPS First Class Free or Upgrade to Priority Mail for faster delivery. Reprinted from original manual using high quality 24lb paper and comb binding. Covers are printed from 65lb cardstock for extra durability. Sales tax charged for Kansas sales. See my for more manuals.  Be sure to add me to your favorites list!
