Rohde And Schwarz Sgmf Tv Television Ntsc Generator 2016.0943.03

US $899.99

  • Richardson, Texas, United States
  • Jan 29th
Rohde and Schwarz SGMF TV Television NTSC Generator 2016.0943.03 The SGMF produces NTSC baseband signals of studio quality complying with the stringent requirements of the RS-170 A standard as regards SC/H phase, burst timing reference and burst width. It is possible to insert the NTSC identification pulse into the first field of the NTSC sequence. Over 30 video signals are avail-able: General-purpose test pattern with optional source identification as well as different, combined test signals for adjusting convergence, brightness and colour during monitor setup NTC7 and FCC test signals Crosshatch-and-dot pattern Signals for measuring amplitude and group delay responses (multiburst, multipulse, H sweep, sin x/x) Squarewave signals (bounce, 60 Hz, 15 kHz, 250 kHz, pulse-and-bar signal) Ramp and staircase signals Colour bar signal and red field Special signals (pluge, coring, VIRS, eye test) and black burst Using the genlock option it is possible to insert any of these signals into the field blanking interval of a program signal. All generator functions including level setting can be remote-controlled via the IEC/IEEE bus Powers up ok.  Front panel buttons work. No further testing performed. May need calibration. Power cord not included. Has scuffs, scrapes, stickers and sticker residue. May ship via Fedex.
