Rohde & Schwarz Fsiq3 Vector Signal Analyzer, 20 Hz To 3.5 Ghz Plus Options

US $5,975.00

Oceanside, California, United States
Jan 29th

Open on mobile:
QR code

Rohde & Schwarz FSIQ3 VSA DESCRIPTION The R&S FSIQ3 / Rohde & Schwarz FSIQ3 Vector Signal Analyzer with a frequency range of 20 Hz to 3.5 GHz was designed for the 3G radio generation. Features of the R&S FSIQ3 Vector Signal Analyzer include: RBW of 1 Hz to 10 MHz in 1/2/3/5 steps 5-pole resolution filters with high selectivity FFT filter with 1 Hz to 1 kHz RBW for fast measurements Displayed average noise floor of -150 dBm typ., in 10 Hz bandwidth Ultrawide dynamic range of 75 db ACPR for WCDMA (4.096 MHz integration BW) 82 dB ACPR in altenate channel for WCDMA Total level uncertainty <1dB up to 2.2 GHz, <1.5 dB up to 3.5 GHz True RMS detector for high-precision power measurements irrespective of waveform Fast spectrum analysis with 5 ms sweep time for full span Fast time domain analysis with 1 Aµs zero span sweep time Integrated broadband vector signal analyzer for all main mobile radio standards and modulation modes with versatile result display. I and Q signal, magnitude and phase, vector and constellation diagrams, spread sheets with numeric evaluation of modulation errors and demodulated bit sequence. The Rohde & Schwarz FSIQ3 provides comprehensive and easy to use measurement functions in the: Frequency Domain: In the frequency domain, the R&S FSIQ3 measures intermodulation and harmonics with great accuracy. The high 3rd-order intercept point in conjunction with the extremely low noise floor yields an intermodulation- free dynamic range of >110 dB and ensures reliable performance of even sophisticated measurements. The excellent dynamic range and the optimized phase noise values make the R&S FSIQ3 an ideal tool for ACPR (adjacent- channel power ratio) measurements in all mobile radio systems and in particular for WCDMA. The maximum ACPR value for WCDMA in 4.096 MHz bandwidth is 75 dB and is already attained at -12 dBm input level. The RMS detector available for all bandwidths up to 10 MHz is the ideal tool for precise power measurements whatever the waveform. Channel power and adjacent- channel power can accurately be measured and displayed irrespective of any signal statistics. Measurement challenges such as repeatability of power measurement of modulated signals (e.g. CDMA) can thus be eliminated. Time Domain: In the time domain, the R&S FSIQ3 features all modern capabilities of burst analysis in TDMA systems; gate functions, trigger delay and integrated RF trigger in conjunction with a short sweep time of 1 Aµs ensure precise measurement of the timing characteristics of all main mobile radio systems. Thanks to the wide range of bandwidths available up to 10 MHz the effect of the measuring instrument becomes negligible, in particular in the case of measurements on broadband systems. Various marker functions in conjunction with editable gated sweeps allow RMS, average and peak measurements to be carried out over any selectable time. Modulation Domain: In the modulation domain, the integrated vector signal analyzer provides diverse measurements on signals with digital or analog modulation. The variety of settings that can be called simply at a keystroke covers 18 mobile radio standards from GSM, NADC, IS95 through to WCDMA. These convenient presettings make it superfluous for the user to spend valuable time in looking up specifications and go towards enhancing the measurement reliability. Display of the results caters to practically each and every need: in addition to vector and constellation diagrams, I/Q signal and eye/trellis diagrams, tables with modulation errors including the demodulated bit sequence are particularly useful. EVM (error vector magnitude), phase and frequency error, waveform factor and I/Q offset are output as numeric values, with RMS and peak value being shown separately. Besides the mobile radio standards, the R&S FSIQ3 can also be used as a general-purpose measurement demodulator for non-standard modulation methods. The list of the 13 digital demodulators available ranges from BPSK, QPSK and (G)MSK through to 16QAM. With a symbol rate selectable up to 6.4 Msymbol/s and cosine and root-cosine filters adjustable in 0.01 step width, configuration of customized systems is no problem. The analog demodulators using digital technique throughout feature longterm and temperature-independent measurements, e.g. of transmitter transients, or convenient measurement of incidental phase modulation (AM to ?M conversion) e.g. on travelling wave tubes. This unit comes with the following options: B12 - Switchable Attenuator for Tracking Generator B16 - Ethernet B17 - 2nd IEC/IEEE Interface Connector B22 - Enhance, 10 MHz -2 GHz B9 - Tracking Generator K11 - GSM BTS Test FW *All of our equipment has been tested. Additional calibration may be available upon request! ~This sale includes all items shown, a power cord, and manual on CD (when available)~ PAYMENT AND SHIPPING INFO Warranty Info & Return Policy All goods or equipment sold by AxiomTest include a 30-Day Domestic Warranty. Warranty period starts the day the equipment is shipped. AxiomTest will at its discretion, repair, replace, or refund the selling price for any malfunctioning equipment or goods, provided payment is made in due course, except in cases of improper application or misuse of goods or equipment by Customer. Shipping costs are not refundable. All goods or equipment sold by AxiomTest are subject to a limited 5-day Domestic ROR (Right of Return) unless otherwise noted. This ROR is limited to goods found to be non-acceptable due to cosmetic defect (not previously disclosed) or item not meeting manufacturer's spec as advertised. ROR does not apply to wrong item(s) ordered by customer. All items past the 5-day ROR period will be accepted only under written acceptance by AxiomTest. Customer agrees to pay all return shipping costs for any returned item. Items that are damaged in shipping are not covered under ROR terms. Items misused or damaged by customer's misuse (intentional or unintentional) are not covered by ROR. ROR does not apply to rental orders. Returns must be shipped with all original packaging and accessories. We will not accept any items with obvious signs of additional wear and tear or internal component alterations. All of our items will ship with “Warranty Void” tamper resistant stickers. If any stickers have been removed or tampered with your refund will be canceled. Please include your order number and a brief description as to the reason for returning the item(s). SORRY - RETURNS WILL NOT BE ACCEPTED FOR ORDERS PLACES OR SHIPPED OUTSIDE OF THE U.S. Payment Options USA Bidders- PayPal, Money Order, Wire Transfer, Company Check, Personal Check or Bank Check. All funds must be in US Dollars- no exceptions. Unsecured funds must clear prior to shipment (typically 7-10 days after I receive the funds). International Bidders: Wire transfer of funds (US dollars only- a $25 wire transfer fee will apply) and PayPal where available. NO CREDIT CARD PURCHASES ARE ACCEPTED. Shipping Unless noted otherwise, all shipments within the USA are done through UPS or FedEx Ground (up to 5 Business days for processing). If you have an account with a shipping service or your own method of shipping and would like to utilize that source please allow 5-7 business days for shipment to occur. Shipments are delivered to all US addresses, including military addresses. Saturday and Residential delivery are available at an additional third party charge depending on the shipping method you choose. We now offer shipping outside of the United States. However, some international laws prohibit us from shipping certain items to certain countries. Additionally, not all countries are supported by our service provider. Our international rates are not always the best, so you may also elect to use your own freight/shipping account through FEDEX or DHL. We are not set up to ship via USPS, and we will NOT falsify any import documents for international orders - no exceptions. Additionally, your international order may have applicable duties and taxes for shipping an item into your country. Please contact us to accurately quote and invoice these fees PRIOR TO CHECKOUT. Please note: In all sales where an item is prohibited to ship internationally to a successful buyer, that buyer will be notified of non-shipment and a full refund will be made. We reserve the right not to ship any item internationally that is controlled by the US Department of Commerce’s laws and regulations and deemed non-shippable to that region of the world or to listed individuals. *eBay's International Shipping calculations do not include any additional duties, fees, or VAT that may be associated with importing this item into a foreign country - please bid accordingly* Sales Tax California residents will be charged sales tax if no resale or tax exempt form is submitted prior to payment. ******CALL (760) 806-6600 TO RENT THIS ITEM****** TRIED, TESTED...ACCEPTED.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Fully tested and Guaranteed Working!”
