RIGOL DG1022U DG1022A Arbitrary Waveform Function Generator 25Mhz Harmonic sine New OWON 100Mhz thin Oscilloscope SDS7102 1G/s 8"... New MS5308 Portable Handheld AutoRange LCR Meter 1... New SMD SMT 0805 1% resistor kit 0 10M ohm 144V 10... Brand New RIGOL Function/Arbitrary Waveform Generators DG1022U DG1022A 25Mhz AWG Brand new with 3 yrs warranty, best quality/value AWG on the market DG1022U function/arbitrary waveform generators use Direct Digital Synthesis (DDS) technology. They could generate accurate, stable, clean, low distortion signals. Adopt advanced DDS technology; dual channel output; 100 MSa/s maximum sampling rate; 14 bits vertical accuracy Output 5 standard waveforms; built-in 48 arbitrary waveforms Abundant modulation functions: AM, FM, PM, FSK, linear/logarithm sweep and burst Abundant output and input: waveform output;synchronous signal output; external modulation source, external 10 MHz reference clock input,external trigger input Unique channel coupling and channel copy Built-in high precision and wide band counter, the measurement range: 100 mHz ~ 200 MHz (single channel) Standard configuration interfaces: USB Device & USB Host, and support U-disc storage Seamlessly interconnect with DS1000 series digital oscilloscope Powerful arbitrary waveform editing software“UltraWave” Support remote control by commands A variety of display modes Clear graphical interface Support Chinese and English menu and input Button-help makes information getting easier File management (support for USB flash device and local storage) Advanced functions 1?Hz frequency resolution 2mV minimum range (50 Ohm) 200 MHz built-in frequency counter Dual channel output Channel coupling and copy 48 built-in arbitrary waves Clear graphical interface Chinese/English language interface Backlight display File management Model DG1022U Standard Waveforms Sine, Square, Ramp, Pulse, Triangle, Noise, Arb Sine 1 ?Hz to 25 MHz Square 1 ?Hz to 5 MHz Pulse 500 ?Hz to 5 MHz Ramp/Triangle 1 ?Hz to 500 kHz Arb 1 ?Hz to 5 MHz Resolution 1 ?Hz Accuracy Within 90 days: 50 ppm Within 1 year: 100 ppm, 18°C - 28°C Temperature Index < 5 ppm/°C Sine Wave Spectral Purity Harmonic Distortion < 1 Vpp > 1 Vpp DC to 20 kHz -70 dBc -70 dBc 20 kHz to 100 kHz -70 dBc -60 dBc 100 kHz to 1 MHz -55 dBc -50 dBc 1 MHz to 10 MHz -40 dBc -35 dBc Total Harmonic Distortion DC to 20 kHz 1Vpp >0.2% Spurious (non-harmonic) DC to 1 MHz < -70 dBc 1 MHz to 10 MHz < -70 dBc + 6 dB/octave Phase Noise 10 kHz Offset –108 dBc / Hz, typical Square Wave Characteristic Rise/Fall Time < 20 ns (10% to 90%) Overshoot < 5% Duty Cycle 1 ?Hz (include) ~ 3 MHz (include) 20% to 80% 3 MHz (non-include) ~ 4 MHz (include) 40% to 60% 4 MHz (non-include) ~ 5 MHz (include) 50% Asymmetry (below 50% Duty Cycle) 1% of the period + 20ns Jitter 6 ns + 0.1% of the period Pulse Wave Characteristics Pluse Bandwidth 2000s max,20ns min?C1ns min resolution Overshoot < 5% Jitter 6 ns + 100 ppm of the period Arb Wave Characteristics CH1 CH2 Waveform Length 2 to 4k points 2 to 1k points Amplitude Accuracy 14 bits (including sign) 10 bits (including sign) Sample Rate 100 MSa/s Minimum Rising /Falling Time 35 ns Jitter (RMS) 6 ns + 30 ppm Non-Volatile Storage 10 waveforms Output Characteristics Amplitude 2 mVPP to 10 VPP (50 ?) 4 mVPP to 20 VPP (High Z) 2 mVPP to 3 VPP (50 ?) 4 mVPP to 6 VPP (High Z) Amplitude Accuracy (1 kHz) ± 1% of setting + 1 mVPP Amplitude Flatness (sine wave relative to 100 kHz) <100 kHz 0.1 dB 100 kHz ~ 5 MHz 0.15 dB 5 MHz ~ 20 MHz 0.3 dB DC Offset Range (peak AC ?{ DC) ±5V (50 ?) ±10 V (High Z) ±5V (50 ?) ±10 V (High Z) Accuracy ±( 2% of the Offset Setting ± 0.5% (|Voffset|) of the Amplitude ± 2mV) AM Modulation(CH1) Carrier Waveforms Sine, Square, Ramp, Arb Source Internal/ External Modulating Waveforms Sine, Square, Ramp, Noise, Arb (2 mHz to 20 kHz) Depth 0% to 120% FM Modulation(CH1) Carrier Waveforms Sine, Square, Ramp, Arb Source Internal/ External Modulating Waveforms Sine, Square, Ramp, Noise, Arb (2 mHz to 20 kHz) Frequency Deviation DC ~ 5 MHz PM Modulation(CH1) Carrier Waveforms Sine, Square, Ramp, Arb Source Internal/ External Modulating Waveforms Sine, Square, Ramp, Noise, Arb (2 mHz to 20 kHz) Phase Deviation 0 ~ 360° FSK Modulation(CH1) Carrier Waveforms Sine, Square, Ramp, Arb Source Internal/ External Modulating Waveforms 50% duty cycle square (2 mHz to 50 kHz) Sweep(CH1) Carrier Waveforms Sine, Square, Ramp, Arb Type Linear or Logarithmic Direction Up or Down Sweep Time 1 ms ~ 500 s ± 0.1% Source Internal/External/Manual Burst(CH1) Waveforms Sine, Square, Ramp, Pulse, Noise, Arb Types Count (1 to 50,000 periods), infinite, gated Start Phase -180° to +180° Internal Period 1 ?s to 500 s ± 1% Gate Source External Trigger Trigger Source Internal/External/Manual Counter Specification Function Frequency, period, positive/negative Pulse width, Duty cycle Frequency range Single channel: 100 mHz ~ 200 MHz Frequency resolution 6 bits/s Trigger mode Trigger level range?F±3 V ?i0.1?“ ~ 100?“?j Resolution?F6 mV Display 256 Horizontal x 64 Vertical Power 100 to 240 VACRMS?C45 to 440 Hz?CCAT II?CLess than 40 VA Weight 2.7 kg Accessories: 1) Power cord for your country; 2) USB data cable; 3) BNC cable; 4) CD; Shipping: USA order will ship from our USA warehouse by usps priority mail, ALL other orders ( ship to address is not USA) will ship from our China warehouse by air mail with track number, it takes around 7-12 business days to arrive, Brand new with 3 yrs warranty, we are authorized dealer, all machines sold by us got 3 yrs manufacturers warranty, contact us at (408) 329-7985 for any questions, thank you eBay Cross Border Trade powered by MerchantRun GlobalLink

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Manufacturer	RIGOL
Country of Manufacture	China
Model	DG1022U/DG1022A
