Renishaw Tp20 Em2 Carbon Fiber Cmm Probe Module New Stock With Warranty

US $850.00

Minneapolis, Minnesota, United States
Mar 25th

Open on mobile:
QR code

Powered by Frooition Pro Shop Search Renishaw TP20 EM2 Carbon Fiber CMM Probe Module New Stock with Warranty Click here to view full size. Full Size Image Click to close full size. Item Description New Stock in Box with Warranty Renishaw TP20 EM2 Standard Force Stylus Module. The Renishaw EM2 is a standard force module with integral 75 MM carbon fiber extension that connects to your TP20 touch probe body or MH20I probe head. Current list price for the EM2 module is $1211.00 About TP20 The TP20 is a compact 5-way, or 6-way, kinematic touch-trigger probe system. The two-piece design, comprising probe body and detachable stylus module(s), connected using a highly repeatable magnetic kinematic coupling. This provides the facility to change stylus configurations either manually or automatically without the need for requalification of the stylus tips, thereby giving significant time savings in inspection routines. Modules offering a range of trigger forces allow the probe performance to be best matched to the measurement task. A set of probe extensions is also available, as is a 6-way module. The stylus mounting thread accepts styli from the Renishaw M2 range. The TP20 system is easily retrofitted and is compatible with existing touch trigger probe interfaces, extensions and adaptors. System components The system components are: TP20 probe body TP20 probe module - seven variants allow optimisation to suit application MCR20 module changing rack - automatic operation MSR1 module storage rack - manual operation Suitable for interfacing with Renishaw's PI4-2, PI7-2 or PI200 TP20 specification Sense directions All modules except 6W 6W ±X, ±Y, +Z ±X, ±Y, ±Z Suitable interface PI4-2, PI7-2, PI200, UCC Pre-travel variation LF SF / EM1 / EM2 MF EF 6W ±0.60 µm (± 0.000023 in) ±0.80 µm (± 0.000032 in) ±1.00 µm (± 0.000039 in) ±2.00 µm (± 0.000079 in) ±1.50 µm (±0.000058 in) Unidirectional repeatability LF / SF / EM1 / EM2 MF EF 6W ±0.35 µm (± 0.000014 in) ±0.50 µm (± 0.000020 in) ±0.65 µm (± 0.000026 in) ±0.80 µm (± 0.000032 in) Repeatability of stylus changing MCR20 Manual ±0.50 µm (± 0.000020 in) ±1.00µm (± 0.000040 in) Stylus range M2 Mounting method M8 thread Probe modules A range of seven, application specific, probe modules is available and are identified by coloured caps. Module Application Trigger forces Stylus lengths SF - Standard force Suited to the majority of applications XY: 0.08 N Z: 0.75 N Stylus: 10 mm 10 - 50 mm GF LF - Low force Low trigger forces applications - e.g. rubber seals XY: 0.055 N Z: 0.65 N Stylus: 10 mm 10 - 30 mm MF - Medium force Where a higher trigger force than standard is required XY: 0.1 N Z: 1.9 N Stylus: 25 mm 10 - 60 mm EF - Extended force Large stylus assemblies or where vibration causes spurious 'air' triggers XY: 0.1 N Z: 3.2N Stylus: 10 mm 10 - 60 mm 6W - 6-way Measurement in the –Z direction - e.g. undercuts XY: 0.14 N Z: 1.6N Stylus: 10 mm 10 - 50 mm EM1 STD - 50 mm extension Majority of applications requiring a 50 mm extension XY: 0.08 N Z: 0.75 N Stylus: 10 mm 10 - 50 mm EM2 STD - 75 mm extension Majority of applications requiring a 75 mm extension XY: 0.08 N Z: 0.75 N Stylus: 10 mm 10 - 50 mm This sale is for the touch probe module only and does not include the touch probe body. This is by far the best price you will find for a new Renishaw TP20 EM2 stylus module. Why pay retail when you can purchase new with warranty from Metrology Parts. Purchase with confidence from a Paypal verified retailer. If what you order is not what you receive you will be refunded the full purchase price for this sale. Metrology Parts would like the opportunity to earn your business for this sale and all of your future Renishaw product needs. If you have any questions feel free to contact us. With 26 plus years of experience with Renishaw products we can help with all of your application needs as well as your after sales support. About Us Payment Shipping Terms Returns About Us About Us Payment Shipping Terms Returns Payment About Us Payment Shipping Terms Returns Shipping About Us Payment Shipping Terms Returns Terms About Us Payment Shipping Terms Returns Returns Helpful Links More Items! Frooition www.frooition.com | eBay design, eBay store design, eBay shop design, eBay template design, eBay listing design This listing is currently undergoing maintenance, we apologise for any inconvenience caused.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	United Kingdom
MPN	A-1371-0431
Brand	Renishaw
Country of Manufacture	United Kingdom
Model	EM2
