Red Led Digital Frequency Panel Meter 0.56 ?10-99.99khz High Hz Measure 4 Digit

US $12.90

Shenzhen,Guangdong, China
Jun 9th

Open on mobile:
QR code

Store Home Best Deals Wholesale Transaction Terms About Us Test & Meter Terminals Switches Optical Fiber Network / Power Hand Tool Fasteners Product Description Introduction: Digital panel meter adopts the latest model of A/D conversion chip and high stable benchmark IC, use SMT components, circuit design is reasonable. Can be applied to measure voltage, current, also can connect an external sensor to measure temperature, pressure, displacement and other physical quantity. Appropriate for all kinds of digital instrument display. Products have good stability, high measurement precision, strong anti-interference capability. With a standard size, easy to install. Power supply Reverse connection protection! Function: Input Pulse Signal: NPN/PNP Open Collector, Contact Switch, Contactless Switch, Level Pulse Input Signal Voltage: Low Level: -30V-0.6V, High Level: 4-30V Measurement Range: 10-99.99 kHz, Auto-switch Maximum Input Frequency: 100 KHz Main Parameters: Accuracy: ±0.1%+1digit Display Mode: 0.56″Red LED 4 Digits Update Rate: >3 times/sec. Operating Power: DC 8-24V, 40mA External Dimension: 79*42*32mm Installation Dimension: 76*39mm Overrang Display: First digit display “1”or “-1”, the later three digit don't display Note: 1. Connect the plug properly according to the wiring diagram 2. Should Avoid Strong Electromagnetic Interference, measurement wire had better use Shielded Wire or wires twisted pair 3. The switch or circuit of counting semaphore and reset signal input should be near the meter terminals, make the signal wire as far as possible short 4. Avoid interference of high voltage wire and power wire, use shielded wire if it is necessary, the shielding layer connect on the meter terminal “+”. 5. We do not recommend that use mechanical switch or micro switch, for their lifespan are short and will lead to miscount after a long using time; however, magnetically controlled switch is a good choice. Package Content: 1pcs frequency meter Welcome to visit More Test Equipment in Our Store Click Here - Add $3 for Registered Airmail Welcome to visit other items in our Shop X1 20MHz / X10 60MHz Oscilloscope Probe for DS201 DS203 Pocketscope MCX Plug NEW -50~110°C Digital Panel Temperature Meter Thermometer Waterproof Probe Cable 2M NEW 5pcs Silicone High Voltage Banana to Banana Plugs Test Leads Cable 5 Colors 2X Black Red Direct Plug-in Insulated Jacket Alligator Test Clip for Multimeter Screwdriver with Voltage Tester Electrical Tester Pen 220V Power Detector Meter K-Type Thermocouple Probe Thermometer Temperature Sensor -40~750°C Range 93mm NEW DC Power Interface Wire Banana Plug Test Clip Hook Probe Cable Phone Repair USB Digital LCD Watt Meter Power Volt Amp Meter RC Battery Analyzer 60V 100A DC NEW AC 1A 2A 3A 5A 10A 15A 20A 30A 50A Analog AC Ammeter Current Ampere Panel Meter LCD Digital Multimeter+ Beeper Capacitance Volt Ohm Tester Amp AC/DC DT9205A NEW shipping Payment Returns Contoct us Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	RF31026
Operating Power	DC 8-24V, 40mA
Update Rate	>3 times/sec.
Maximum Input Frequency	100 KHz
External Dimension	794232mm
Measurement Range	10-99.99 kHz, Auto-switch
Installation Dimension	76*39mm
Brand	Superbat
Accuracy	±0.1%+1digit
Model	TOOL088-99d99KHZ
Display Mode	0.56?Red LED
Country/Region of Manufacture	China
UPC	Does not apply
