R,l,c Bridge 0.5pf-1000mkf 0.3mkh–1000h 0.1ohm-10mohm Universal Rlc Meter E7-11

US $199.00

Saratov, Russian Federation
Jun 9th

Open on mobile:
QR code

Universal RLC meter E7-11 analog of Lutron, Advantest, Avtech, HP Agilent, NoiseCom, General Radio, Boonton, Anritsu, Fluke and general Electric, but has the same or better characteristics. This device can be used for wide measurement range. Universal RLC meter E7-11 provides inductance, capacitance, dissipation and quality factor measurements of different devices electronic elements. Measurement range: capacitance (C) 0.5pF - 1000mkF; inductance (L) 0.3 mkH – 1000H; resistance (R) 0.1Ohm - 10 MOhm; conductance (G) 0.1 nCm - 1 Cm, tangent loss (tg?) 0.003-0.1 Quality (Q factor) 0.1-30 Universal meter RLC E7-11 is designed to measure inductance, capacitance, dissipation factor, tangent loss of different devices electronic elements. Along with basic functions, non-linear elements capacity determination is possible. Device universal meter RLC E7-11 extending functionality is achieved by applying 30V polarizing voltage to measured object and 30 mA current biases from external source. Measuring principle is based on bridge method. Measurements countdown is performed on device scales measurements at bridge back balance. Devices multi-function allows use it for monitoring and research of various radio technical devices: transmitters,converters, amplifiers, filters, modulators, mixers. Condition: NEW (not used, an old stock). Tested and 100% workable. If necessary, we can provide calibration certificate from Government standardization institute (+145-265usd). Also we can provide other resistance, capacitance and inductance standards, decade box and other etalons. Also we can provide other resistance, capacitance and inductance standards, decade box and other etalons. Please take a look on my other items! If you haven’t found the needed item in my listing, please contact me. I’ll try to help you. Technical characteristics of device Universal RLC meter E7-11: capacitance (C) 0.5pF - 1000mkF; inductance (L) 0.3 mkH – 1000H; resistance (R) 0.1Ohm - 10 MOhm; conductance (G) 0.1 ncm - 1 cm, tangent loss (tg?) 0.003-0.1 Quality (Q) 0.1-30 Measurement accuracy: capacitance ±(0.01 ? + 0.2 pF) (0.5 pF-10 mkF), ±0.02 ? (10-1000mkF); inductance ±(0.02L+0.1 mkH) (0.3-100 mkH), ±0.01 L (100 mkH-10 H), ±0.02 L (10-100 H); resistance ±(0.02 R + 0.05 Ohm) (0.1 -10 Ohm), ±(0.01 R+ 0.05 Ohm) (10 Ohm-1 ?Ohm), ±0.02 R (1 - 10 ?Ohm); tangent loss ± (0.1 tg? + 5-3) quality ± (10 + 0.5 Q)% frequency measurement 1000, 100 Hz, DC. Meter RLC E7-11 is designed to measure inductance, capacitance, dissipation factor, tangent loss of different devices electronic elements. Along with basic functions, non-linear elements capacity determination is possible. Device universal meter RLC E7-11 extending functionality is achieved by applying 30V polarizing voltage to measured object and 30 mA current biases from external source. Measuring principle is based on bridge method. Measurements countdown is performed on device scales measurements at bridge back balance. ?7-11 basic technical characteristics Measurement range: capacitance(?) 0.5pF - 1000mkF inductance (L) 0.3 mkH – 1000H resistance (R) 0.1Ohm - 10 MOhm conductance(G) 0.1 ncm - 1 cm tangent loss (tg?) 0.003-0.1 quality (Q) 0.1-30 Measurement error: capacitance ±(0.01 ? + 0.2 pF) (0.5 pF-10 mkF), ±0.02 ? (10-1000mkF) inductance ±(0.02L+0.1 mkH) (0.3-100 mkH), ±0.01 L (100 mkH-10 H), ±0.02 L (10-100H) resistance ±(0.02 R + 0.05 Ohm) (0.1 -10 Ohm), ±(0.01 R+ 0.05 Ohm) (10 Ohm-1 ?Ohm), ±0.02 R (1 - 10 ?Ohm) tangent loss ± (0.1 tg? + 5-3) quality ±(10 + 0.5 Q)% Power supply: 220 V, 50 or 400 Hz. Power consumption 10 V • A. Dimensions 342x173x332 mm. Weight 9 kg. This and other my items - the result of an electrical laboratory closed down. I will gradually put other electrical appliances and multimeters. Quick sale at an inexpensive price.

“Works fine.”

Country/Region of Manufacture

Russian Federation
