Quatech Serial Card Qsc-200/300 4-port Rs-422/485 Db9 W/ Surge Protection New!

US $1300

  • Sugar Land, Texas, United States
  • May 25th
We are a computer manufacturer located in Texas, selling our excess inventory.  This inventory is comprised of components that were purchased new (never refurbished due to our customer requirements) but never used.  In this listing we have 11 factory new (not refurbished) Quatech QSC-200/300 4-Port RS-422/485 Serial Cards with DB9 cable and all accessories included.   These are brand new, in sealed static bags.  The cards have never been installed and the static bags have never been opened. The card will be shipped in original factory packaging with cable and all original accessories.  I opened one for photograph purposes, all electrostatic safety precautions were taken.  We have 100% Positive feedback and work well with international buyers.  Please see product details below and feel free to ask any questions. Thanks for looking! 101885 Quatech QSC-200/300 PCI serial boards utilize a single PCI slot to provide 2, 4, or 8 independent asynchronous serial ports that share a single interrupt. All PCI registers are properly implemented, so you can be assured that Quatech boards will be good citizens on the PCI bus. The board implements 16750 UARTs containing 64-byte FIFOs.  Using a clock multiplying feature the QSC-200/300 is allowed to achieve data rates up to 921.6 kbps. The RS-422/485 serial boards are available with either 2 or 4-ports. The ports are jumper configurable for either RS-422 or RS-485 in any combination for full and half duplex networks. PCI registers are properly implemented to assure that Plug-and-Play works reliably, and that the board will not cause PCI bus conflicts. Details 2, 4, or 8 independent RS-232 ports 2 or 4 independent RS-422/485 ports Speeds up to 921.6 kbps 16750 UARTs with 64-byte FIFOs (16550 for DSC-100/200/300, with 16-byte FIFOs) Full duplex and half duplex modes supported on -200/300 models PCI 3.0 compliant Full modem control and hardware and software flow control DB-9, DB-25 connectors Surge suppression package available Windows 95/98/Me/NT/2000/XP/Vista/Win7 & Linux support RoHS compliant All Quatech PCI serial boards come with a 5 year warranty Specifications Bus Interface: 32-bit, 33 MHz PCI Bus specification 3.0 compliant OS Support: Windows 95/98/Me/NT/2000/XP/Vista/7, OS/2, DOS, Linux Data Rate: up to 921.6 kbps (max*) Click here to learn more about max data rates. RS-232 Serial Ports: DSC:2 QSC:4 ESC:8 RS-422/485 Serial Ports: DSC:2 QSC:4 (each configurable as RS-422 or RS-485 for full or half duplex) Serial Port Connectors: DSC-100/200/300: 2 DB-9 male (See connector pinout) QSC-100/200/300: HD-44 female or with 4 DB-9 male cable (See connector pinout) QSC-100-D9: HD-44 female or with DB-9 cables (See connector pinout) ESC-100D: VHDCI-68 female or with 8 DB-9 male cable (See connector pinout) ESC-100D-D9: VHDCI-68 male or with DB-9 cable (See connector pinout) -IND: Add surge suppression package to any of the above UARTs: 16750 UARTs with 64-byte FIFOs 16550 UARTs with 16-byte FIFOs (DSC-100/200/300 & ESC-100) Transceiver: MAX3076E or compatible RS-232 Drivers: High Level Output: +5V (min), +5.4V (typ) Low Level Output: -5V (min), -5.4V (typ) Transition Time (THL-TLH): 25 ns (typ) RS-422/485 Drivers: Differential Voltage: +/-3.3V Transition Time (TLH): 52ns (typ) Transition Time (THL): 60ns (typ) RS-232 Receive Buffers: Voltage Range: -25V (max), -25V (max) Transition Time (THL-TLH): 50ns (typ) RS-422/485 Receive Buffers: Differential Input Threshold: ±0.2V Voltage Range: -7V to +12V Common Mode Input Transition Time (THL-TLH): 65ns (typ) IND Option: Surge suppressor applied to each line that is capable of sustaining up to 40A peak, 8 x 20µs transient surges, a clamping voltage of 30V and a peak energy dissipation of 0.1 Joules. (NOTE: The "IND" option limits data rate to 115.2 kbps due to capacitive loading.) Environment: Operating: 0°C to 70°C Storage: -50°C to 80°C Humidity: 10% to 90% Power Requirements: 260mA (+5V) Size: DSC-100/200/300: 4.785” x 3.5” QSC/ESC: 4.725" x 2.5" Certifications: CE, FCC Class B, RoHS and WEEE compliant
