Process Mixer Double Arm Sigma Mixtruder Extruder Vacuum 13gal Battaggion

US $32,500.00

Morgantown, Pennsylvania, United States
Jan 30th

Open on mobile:
QR code

Process mixer Double arm Sigma Mixtruder extruder Vacuum 13gal Battaggion Used sigma type process kneading mixer/extruder in very good clean condition. This machine has dual sigma style mixing blades to mix the product and a screw type discharge screw to extrude the mixed material from the machine. The entire system consists of the main mixing machine, the control cabinet and the temperature control system. Mixing chamber can be evacuated with the onboard vacuum pump. The sigma blades are powered with a 10HP gearhead motor and the extruding screw is powered with a 7.5HP gearhead motor. Motor speed is controlled and monitored by two AC drives that are housed in the vertical control cabinet. Control cabinet also houses all of the fuses, contactors, overloads and control buttons for the system. The temperature regulation system uses electric heaters to heat oil which is then circulated to the jacketed mixing bowl. Using the measured dimensions of the bowl the total capacity was found to be 20.5 gallons. The approximate working capacity would be about 13 gallons or 50 liters. These double arm sigma mixers can be used for base silicones and rubber, mastics, glue, high viscosity adhesives, composite material, color and pigments, special lubricants, brakes compounds, explosives and abrasive products, fine chemicals and more. Machine was wired for 380 V three phase 50 hertz. The motors can run on either 50 or 60 Hz and 400 to 460V. The VFDs appear to be 415 V specific, and 50 to 60 Hz. Other than the VFDs there are not many components to the control system that would need to be considered. To run this system on US electrical service the following changes would need to happen: Method A Power machine with a 460 to 400 V transformer Method B 1. Change VFDs to a 460V units 2. Change control transformer to 460/24V unit instead of 400/24V unit 3. *Thermal overloads may need to be changed The temperature control unit consists of electric heaters and the heater controlling components. The heating elements themselves would most likely be fine to operate on 460V and the control circuit transformer taps moved from 400V to 440V. Some of the fuses may need to be changed. It should be verified that the control board can operate on 60hz. This system is in very good condition. Used mixing machines of any type can accumulate residue which this machine has very little of. Overall appearance of the unit is very good and clean with only a small amount of residue and only a few minor scratches. Series: 9727 Mixing machine: Single discharge screw Model IPC 50 AP Mixing chamber: 14 7/8 x 17 7/8 x 18" deep Double Sigma blade agitators Stainless steel construction Approx 7 gallon working capacity Sigma mixing motor 8.6 kW = 11.5 HP @ 60 Hz (7.5 kW @ 50hZ = 10HP) Siemens motor 440-480V 1755 RPM Gear box Bonfiglioli Type: MAS 60/DP Ratio: 41.4:1 Extruder Output port ID: 2 7/8" (73 mm) Extruder motor 6.3 kW = 8.44HP @ 60 Hz (5.5kW @ 50hZ - 7.4 HP) Siemens motor 440-480 V 1755 RPM Gear box Bonfiglioili Type: C60 2P P132 Ratio: 19.6:1 Overall Dimensions: 53x 93x62"H Top glass viewport: 5.75" square Temperature regulation unit: Corema Termotrol TM/OH 412/15 Heating and cooling 380 VAC 50 Hz Heat: 12 kW (two 6 kW elements) Oil pump delivry: 40 Lt/per min Cooling: 15000 Kcal/h, water pressure from source Overall dimensions:32x17x82" Control Cabinet 31.5x19x77 Sigma blade VFD ABB ACS60100163 380-415V Input 16/24 A output Extruder VFD ABB ACS60100113000C1200000 380-415V input 18/16A output 24V control system Currently setup for 380V Input Specifications: MFG: Battaggion Model: IPC 50 AP Serial: 16696 Volts: 380V Amps: Phase: 3 Drive: Controls: Manuals: Air: Weight: Lbs Condition: Very good and clean Length: Width: Height: All dims inches unless otherwise noted Inventory #: 5325 For more information call 610-286-1655. Please call or email for shipping rates. International purchases: A $40 documentation processing fee will be added to total purchase for items under $150. When communicating with us please use your own email address or call 610-286-1655. We want to know who we are communicating with and we cannot identify specific emails in our inbox using the ebay email system. Send emails to heritageequipment AT gmail.com The new ebay buyer protection program has inspired us to offer all of our items “as-is”.This does not mean that you are buying a machine with deficiencies, known or unknown. What it means is that some of our items will be tested and will include the results in the description and others will be untested but described accurately to the extent that is possible without actually powering up the machine. In addition to this written description you will have the opportunity to view high quality photos of the item. With these two sources of information you will have as much information as possible without being physically here to inspect the machine. Feel assured that we will make a diligent effort to give you an accurate description of the equipment. As a buyer you should be aware that you are buying an expensive piece of equipment at a greatly reduced price and as such you may have to deal with certain unknowns and defective components which were not known and could not be known without full scale setup and operation of the machine. Our experience in dealing with many specialized pieces of equipment has proven this to be a rare occurrence however it is a risk inherent in buying used equipment. The very few times we have had to deal with these issues we have been very helpful in resolving the problem.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Very good and clean”
