Precision Handheld Lcr Meter From Escitec

US $2700

  • Mesa, Arizona, United States
  • May 27th
Technical Specifications: Measurement capabilities: Inductance, capacitance, AC resistance (denoted as R), DC resistance (DCR), dissipation factor D, quality factor Q and phase angle Five device test frequencies: 100hz, 120hz, 1khz, 10khz, 100khz Test amplitude: 0.6V RMS Product images showing component test images: 910pf +/-5% silver mica capacitor under test @ 100khz (941.4 pf) Nominal 100pF capacitor under test @100khz Nominal 100uH inductor under test @100khz Nominal 10uF Al electrolytic capacitor (4kohm parallel resistance) @ 100hz Nominal 10uF tantalum electrolytic capacitor (12kohm parallel resistance) @ 100hz Models series/parallel equivalent resistance Function switch toggles between L-C-R measurements Guarded test leads 4 terminal measurement configuration Built in test fixture Includes: Test probes Calibration shunt 6 each 1.5V AAA carbon-zinc battery - Backlit display Black zippered carry bag More information at escitec.com
