Phoenix Contact Thermoelectric Voltage Terminal Block Mtkd-nicr/ni - 3100062 New

US $9.00

  • King George, Virginia, United States
  • Mar 3rd
This Listing Is For A NEW Phoenix Contact Thermoelectric voltage terminal block MTKD-NICR/NI - 3100062 General Number of levels 1 Number of connections 2 Color gray Insulating material PA Inflammability class according to UL 94 V0 Connection in acc. with standard IEC 60947-7-1 Maximum load current 1 A (with 4 mm? conductor cross section) Nominal current IN 1 A Nominal voltage UN 400 V (Voltage to the neighboring feed-through terminal block MTK.) Maximum load current 1 A (with 4 mm? conductor cross section) Open side panel ja Dimensions Width 10.4 mm End cover width 1 mm Length 46.2 mm Height NS 35/7,5 39.9 mm Height NS 35/15 47.4 mm Height NS 32 44.9 mm Connection data Connection in acc. with standard IEC 60947-7-1 Connection method Screw connection Conductor cross section solid min. 0.2 mm? Conductor cross section solid max. 4 mm? Conductor cross section AWG/kcmil min. 24 Conductor cross section AWG/kcmil max 12 Conductor cross section stranded min. 0.2 mm? Conductor cross section stranded max. 2.5 mm? Min. AWG conductor cross section, stranded 24 Max. AWG conductor cross section, stranded 14 Stripping length 7 mm Internal cylindrical gage A3 Screw thread M3 Tightening torque, min 0.6 Nm Tightening torque max 0.8 Nm If You Have Any Questions Please Call 540-413-6934 Location: WH1 Rack 2 Shelf 3 On Top Of Red Lion
Item Is Missing Original Packaging
Brand Phoenix Contact
MPN 3100046
Model MTKD-NICR/NI
Country/Region of Manufacture Poland
