Ov7670 Cmos Camera Module Lens Cmos 640x480 Sccb Compatible W/ I2c Interface

US $7.99

  • Shenzhen, China
  • Jan 29th
OV7670 CMOS Camera Module Lens CMOS 640X480 SCCB Compatible W/ I2C Interface Description Photosensitive Array: 640 x 480; IO Voltage: 2.5V to 3.0V; Operating Power: 60mW/15fpsVGAYUV; Sleeping Mode: <20 uA; Operating Temperature: -30 to 70 deg C.; Output Format: YUV/YCbCr4:2:2 RGB565/555/444 GRB4:2:2 Raw RGB Data (8 digit); Lens Size: 1/6"; Vision Angle: 25 degree; Max. Frame Rate: 30fps VGA; Sensitivity: 1.3V / (Lux-sec); Signal to Noise Ratio: 46 dB; DynamicRange: 52 dB; Browse Mode: By row; Electronic Exposure: 1 to 510 row; Pixel Coverage: 3.6um x 3.6um; Duck Current: 12 mV/s at 6'C Application: -High sensitivity for low-light operation; -Low operating voltage for embedded application; -Standard SCCB interface compatible with I2C interface; -Raw RGB, RGB (GRB4:2:2, RGB565/555/444),YUV(4:2:2) and; YCbCr(4:2:2)output format; -Support VGA, CIF and from CIF to 40 x 30 format; -Vario Pixel method for sub-sampling; Auto Image Control: AEC, AGC, AWB, ABF, ABLC; -Image Quality Control: Color saturation, hue, gamma, sharpness and anti-blooming; -ISP includes noise reduction and defect correction; Support image scaling; Lens shading correction; -Flicker 50/60Hz auto detection; -Color saturation level auto adjust; -Edge enhancement level auto adjust; -De-noise level auto adjust Package Included: 1 x VGA OV7670 CMOS Camera Module Lens Payment PayPal is our only accepted method of payment. We accept PayPal payments from buyers all over the world. PayPal is the safest, easiest and quickest way to make online purchases. If you do not already have a PayPal account, simply click on the 'Buy It Now' button and follow the eBay checkout instructions. You will then be able to enter your card details in order to pay via PayPal even if you do not already have a PayPal account. Paying via PayPal also ensures that your purchase is fully protected and guaranteed. If you are having difficulty processing your payment, please contact us freely via ebay message center . Delivery details Shipping to US : USPS with the tracking number (10-15 working days) To UK ,Australia ,Canada without tracking number (20-25 working days) To Russia : due to the overstock in the Russia post office (35-45 working days ) To other countries take 30-35 working days Note: the package value over 40USD will add tracking number free . Feedback Refelect 1. We take care of each customer's feedback. If you received product and like it, kindly leave positive feedback with full stars for us. We will be appreciate that and offer better service in the further. 2. Any disatisfied with item, kindly contact with us, we will offer our best service for you. 3. We believe all the question can be solved through friendly communication. Return Policy 1. We will re-send a new item to you if we make mistake to offer a wrong product. 2. We are not responsible for people or shipping damage. 3. If you are willing return item back to us, please keep it in original package. Thanks. Contact us Please take free to contact us if have any questions. Engineered for professional eBay sellers!
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Unbranded
Country/Region of Manufacture China
