Optex Ax-250mkii Photoelectric Detector Receiver And Transmitter

US $41

  • Stockton, California, United States
  • Jun 1st
AX-250MKII is a cost-effective, long range photoelectric detector for internal or external applications. Suitable for external ranges up to 250ft. outdoors, the beams have twin infrared transmitters and receivers to reduce the potential for alarms from small animals, blowing debris and falling leaves. Beams operate by only triggering an alarm when both beams are broken simultaneously. Initial alignment can be carried out using the built in optical aiming device to roughly set the sensors and then fine-tuning can be carried out using a standard volt meter. Features:  Lightning and surge protection Anti-frost design Twin beams require simultaneous interruption to create activation 99% beam blocking stability A.G.C circuit adjustable beam interruption time Specs: Power Input: 10-30 VDC Current Draw (Arming Status): 60mA MAX Current Draw (During Arignment)120mA Alarm Output: Form C. DC 28V, 0.2A MAX Alarm Memory: 0-1 VDC when armed D.Q.: form C. DC 28V, 0.2A MAX Coverage: 250ft. Outdoor / 500ft. Indoor Dimensions: 15.7" x 3.9" x 4"
