Olimex Pic-mt Microchip Buttons, Lcd, Relay Board No Pic Supplied

GBP 16.95

Northampton, United Kingdom
Jan 29th

Open on mobile:
QR code

YOU NEED TO BUY YOUR OWN 28 PIN PIC FOR THIS BOARD E.G. PIC18F876 FEATURES ICSP/ICD connector for programming with PIC-MCP-USB, PIC-MCP or PIC-PG1, PIC-PG2, PIC-PG3, PIC-PG4 and debugging with PIC-ICD2, PIC-ICD2-POCKET, PIC-ICD2-TINY(* for the PICs with ICD support) for PIC16F87X there is low cost PIC-ICD1 Dallas touch button port Frequency input 0-10V and 0-5V ADC input with buffer OAMP RS232 DB9 female connector RS232 interface circuit with Tx, Rx signals RS232 TTL levels output connector Voltage regulator +5V, 78L05 and filtering capacitors Quartz crystall oscilator circuit 20Mhz DIL28 microcontroller socket Relay with 10A/250VAC contacts Buzzer Status LED on RB4 Four mounting holes Power plug-in jack FR-4, 1.5 mm (0,062"), green soldermask, white silkscreen component print Dimensions 120x36 mm (4,7x1,4") DOCUMENTS PIC-MT.pdf Tutorial how to use PIC-MT with CC5X C compiler (in Spanish) written by our Chilian Distributor. HARDWARE PIC-MT schematic REV-D PIC ICSP connector SOFTWARE Blink LED for PIC16F876 demo code (C source and HEX) Buzzer, relay, buttons for PIC16F876 demo code (C source and HEX) LCD write demo code for PIC16F876 demo code (C source and HEX) RS232 send receive for PIC16F876 demo code (C source and HEX) Powered by eBay Turbo Lister Business seller information Olimex Ltd Contact details Jason Moore Sweetacres The Knoll, Grendon Northampton Northamptonshire NN7 1JG United Kingdom Phone:01933|666989 Email:ebay@olimex.co.uk Trade Registration Number: 7280533 Value Added Tax Number: UK 991828568 Return policy To qualify for a hassle-free return, you must pay with PayPal and have the item shipped to a US address. The item must be returned in the same condition it was received. See terms and conditions - opens in a new window or tab. After receiving the item, open a return within Return shipping 14 days You pay return shipping
