Nf Electronics 5020 Frequency Response Analyzer

US $999.00

  • Sydney, New South Wales, China
  • Jan 29th
Open on mobile:
QR code
5020 Frequency Response Analyzers  / Working   No Any other accessories comes with !   Its cosmetics condition as Pictures. A frequency response analyzer measures the gain and phase response characteristics with respect to frequency of the device or system under test, by applying a frequency swept sine-wave to it and examining its response signal. Featured wide dynamic range realizes high precise measurement, and also ultra low frequency measurement. For versatile use 10mHz to 20kHz Built-in CRT output of video printer Equalizer function Specification Model 5010A 5020 5080 Frequency range 10mHz to 20kHz 10mHz to 20kHz 0.1mHz to 2.2MHz Oscillator Frequency resolution 4 digits 4 digits 4 digits Output waveform , , Output voltage 10mV to 5Vrms 10mV to 5Vrms 1mV to 10.0Vo-p Isolation voltage - - ± 500V to chassis ± 300V to analysis input Analyzer No. of input channel 2 2 2 Input voltage range selection Auto ranging Auto ranging Auto ranging Max. input voltage : 300Vo-p (AC+DC) Isolation voltage ± 14.2V (floating) ± 14.2V (floating) ± 500V to chassis ± 300V to oscillator common Analysis mode CH1/OSC, CH1/CH2 CH1/OSC, CH1/CH2 CH1, CH2, CH1/CH2, CH2/OSC DC bias elimination Automatically eliminated over the entire frequency range Integration cycles 1 to 100 1 to 100 1 to 9999 cycles Judgement function UNDER, GO and OVER - - Display device Indicator tube CRT (green) LCD Display mode log R • ?, numerical Nyquist, Bode and Nichols diagram, numerical a•b, R • ? , log R • ? , numerical Miscellaneous External display device - video printer, plotter (HPGL) plotter (HPGL) Memory 10 spots 10 panel settings and 2 measurement data 10 panel settings and 2 measurement data Interface GPIB GPIB GPIB Power requirements AC100, 120, 220 or 240V switchable AC100, 120, 220 or 240V switchable AC90 to 132V, 180 to 250V switchable Dimensions (mm) 432(W) X 132.5(H) X 400(D) 432(W) X 132.5(H) X 400(D) 432(W) X 177(H) X 550(D) Weight approx. 9.5kg approx. 12.5kg approx. 17kg
