New Swagelok 6lvv-msm-ald3et-w3-p-csl Ald Diaphragm Valve, Asm Pn: 50-125108a96

US $2000

Phoenix, Arizona, United States
Jun 23rd

Open on mobile:
QR code

NEW Swagelok 6LVV-MSM-ALD3ET-W3-P-CSL Atomic Layer Deposition (ALD) Diaphragm Valve, ASM PN: 50-125108A96 Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from ASM and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This is new, old ASM stock. ASM Information: Part Number: 50-125108A96 Description: VALVE-PNEU ALD 3 PORT NC 1 1/8 W/SENSOR Swagelok Information: Part Number: 6LVV-MSM-ALD3ET-W3-P-CSL Description: 200C ALD VALVE Link to the Datasheet: Swagelok ALD-Series Atomic Layer Deposition Diaphragm Valve Datasheet Breakdown By Part Number: Material: 316L VIM-VAR-Stainless Steel Platform: Modular Surface-Mount, 1.125" Actuator Series: ALD3 Series with Thermal Actuator, Normally Closed Seal: W-Seal Number of Ports: 3 Additional Options: Electronic Actuator-Position sensor with Long Cable with Flying Leads Electrical Connector Key Features: Ultrahigh cycle life with high-speed actuation CV range from 0.27 standard Up to 392°F (200°C) capability with thermal actuators Electronic actuator position-sensing option Suitable for ultrahigh-purity applications with 316L VIM-VAR stainless steel body Modular surface-mount end connection Specifications: Working Pressure: Operating1: Vacuum to 145 psig (10.0 bar) Burst: > 3200 psig (220 bar) Temperature Rating: Operating2, 3 - Thermal Actuator2: 32°F to 392°F (0°C to 200°C) Short Term Bakeout: 392°F (200°C) - valve open Flow Coefficient4: 0.27 CV Internal Volume: 0.048 in3 (0.79 cm3) Orifice: 0.16 in. (4.1 mm) Pneumatic Actuator5: Actuation Pressure: 50 to 90 psig (3.5 to 6.2 bar) Air Displacement: 0.042 in3 (0.69 cm3) Notes: 1: Recommendde operating pressure of less than 35 psig (2.4 bar) for optimal cycle life. 2: Actuator temperature is limited to 248°F (120°C); valve body temperature is rated to 392°F (200°C). 3: See pages 11 and 12 (in the datasheet) for maximum operating temperatures for products with an electronic actuator-position sensor, solenoid pilot valve, or both. For More Pictures Please Click the Following: Picture 2 - Side View #1 Picture 3 - Side View #2 Picture 4 - Swagelok Part Number Tag Picture 5 - ASM Part Number Tag For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $10.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 12/11/12
