New Pir Motion Sensor Detector Module Hc-sr501 Adjust Ir Pyroelectric Infrared

US $1.47

  • CN, China
  • Mar 28th
New PIR Motion Sensor Detector Module HC-SR501 Adjust IR Pyroelectric Infrared Product Type: HC--SR501 Body Sensor Module Operating voltage range: DC 4.5-20V Quiescent Current: <50uA Level output: High 3.3 V /Low 0V Trigger: L can not be repeated trigger/H can be repeated trigger(Default repeated trigger) Delay time: 5-200S(adjustable) the range is (0.xx second to tens of second) Block time: 2.5S(default)Can be made a range(0.xx to tens of seconds Board Dimensions: 32mm*24mm Angle Sensor: <100 ° cone angle Operation Temp: -15-+70 degrees Lens size sensor: Diameter:23mm(Default) Features: 1, the automatic sensor: to enter the sensor output range is high, people leave the sensor range of the automatic delay off high, output low. 2,the photosensitive control (optional, factory is not set) may set the photosensitive control during the day or light intensity without induction. 3, the temperature compensation (optional, factory is not set): In the summer when the ambient temperature rises to 30 ~ 32 °C, slightly shorter detection range, temperature compensation can be used as a performance compensation. 4, two trigger mode: (can be selected by jumpers) a, can not repeat the trigger: the sensor output high, the delay time is over, the output will automatically become low from high; b, repeatable trigger: the sensor output high after the delay period, if the human body in its sensing range activities, its output will remain high until after the delay will be left high to low (sensor module review Measured activities of each body will be automatically extended after a delay time, and the final event of the delay time Starting point of time). 5, with induction blocking time (the default setting: 2.5S block time): sensor module, after each sensor output (high change Into a low level),you can set up a blockade followed by time period, in this time period the sensor does not accept any sensor signal. This feature can have a "sensor output time" and "blocking time" the interval between the work produced can be applied to detect the interval Products; also inhibit this function during load switching for a variety of interference. (This time can be set at zero seconds - Tens of seconds). 6, the working voltage range: the default voltage DC4.5V-20V. 7, micro-power consumption: static current "50 microamps, especially for battery-powered automatic control products. 8, the output high level signals: types of circuits can be easily and docking. Instructions: 1. Sensing module for about a minute after power initialization time, during the interval to the output module 0-3 times a minute in standby mode. 2. Should avoid direct lighting such as interference sources close the surface of the lens module so as to avoid the introduction of interference signal generator malfunction; use of the environment to avoid the flow of the wind, the wind sensor will also cause interference. 3. Sensor module using a dual probe, the probe's window is rectangular, dual (A per B million) in the direction of the ends of long, when the body passed from left to right or right to left when the reach the dual IR time, distance difference, the greater the difference, more sensitive sensors, when the body from the front to the probe or from top to bottom or from bottom to top direction passing, dual IR not detected changes in the distance, no difference value, the sensor insensitive or does not work; so the sensors should be installed dual direction of the probe with human activities as much as possible parallel to the direction of maximum to ensure that the body has been passed by the dual sensor probe. To increase the sensing range of angles, the module using a circular lens, the probe also makes sense on all four sides, but still higher than the upper and lower left and right direction of sensing range, sensitivity and strong, still as far as possible by the above installation requirements.VCC, trig (control side), echo (receiving end), GND 4. Dimensions and Adjustment: Note: The potentiometer clockwise to adjust the distance, sensing range increases (about 7 meters), on the contrary, sensing range decreases (about 3 meters).Delay adjustment potentiometer clockwise rotation, sensor delay longer (about 300S), the other hand, induction by the short delay (about 5S). 5. Applications a, Security Products b, the human body sensors toys c, the human body sensor lighting d, industrial automation and control, etc. It can automatically and quickly open various types of incandescent, fluorescent lamps, buzzer, automatic doors, electric fans,automatic washing machine and dryer Machines and other devices,is a hightech products. Especially suitable for enterprises, hotels, shopping malls, warehouses and family aisles, corridors and other sensitive Sense of region, or for the security zone automatic lighting, lighting and alarm systems. Package Included:     1 x Adjust IR Pyroelectric Infrared IR PIR Motion Sensor Detector Module HC-SR501 We accept Paypal only.All major credit cards are accepted through secure payment processor PayPal.Payment must be received within 7 business days ofauction closing.If you have bought multiple items from me, you can send me one payment for all the items instead of paying for them individually. When you click the Pay Now button, eBay will automatically determine if there are other items you have won or purchased from me and will combine them for your review.   This is an international transaction. Import duties, taxes and charges are not included in the starting price or shipping charges. Please check with your country’s customs office to determine what these additional costs will be prior to bidding/buying. Country Delivery Time Working Days 7-10 10-18 18-25 25-35 35-45 >45 Calendar Days 9-12 12-22 22-28 28-38 38-50 >50 United States Rate of Delivery 5.1% 50.1% 29.6% 10.5% 4.7% Refund United Kingdom Rate of Delivery 9.9% 63.2% 19.1% 3.4% 4.4% Refund Australia Rate of Delivery 21.4% 50.0% 14.3% 7.2% 7.1% Refund France Rate of Delivery 10.5% 28.6% 43.8% 10.1% 7.0% Refund Germany Rate of Delivery 11.1% 22.2% 30.3% 20.9% 15.5% Refund Canada Rate of Delivery 0.0% 47.1% 31.4% 17.6% 3.9% Refund Spain Rate of Delivery 3.5% 25.0% 47.9% 12.9% 10.7% Refund Other remote areas: Russia, Brazil, Argentina, Sri Lanka, India, Ukraine may need more than 35-55days!Please note!thanks Please contact us if the item has not arrived within 30 days for any reason. We reserve the right to refuse the order for bidders with zero, negative or hidden feedback and all non-registered bidders which is reported from ebay. If there are any issues with the purchase, please contact us before leaving negative feedback. Please bid ONLY if you agree to the above terms.Every customer is important for us, if you are happy with our service and product please give us positive feedback, thank you for your effort!If you are not happy with us please give us a chance to resolve the problem for you, 100% satisfaction! Warranty and Guarantee: If you are not satisfied when you receive your item, please return it within 14 days for a replacement or money back. Please contact me before you return it. Our working time: Beijing time : Monday to Friday 8:30 am to 5:30 pm. We do not work holidays in China If you send email to us,In our working hours will be resumed within 24 hours. If you we are not satisfied with the product or service ,please contact me and don't give us negative or natural feedback,We must give you a satisfactory solution. Feedback & DSRs (Detailed Seller Ratings). We depend on our eBay reputation and customer satisfaction to succeed.Therefore, Your feedback and DSRs are extremely importantto us as better DSR scores affect our search placement on eBay.  We would like to earn your good feedback and 5 star DSR rating. Your action will help us offer our milk and bread . If we have not given you reason enough for 5-star grades on each DSR then please let us know how we can earn your 5-star rating before submitting yourscores! thanks so much~ eBay Cross Border Trade powered by Channel Effect On Mar-28-15 at 02:56:41 PDT, seller added the following information:
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand 100%NEW
Type Motion Detectors
Model HC-SR501
About Us Only best quaity product,please choose us.
MPN IR Pyroelectric
