New LCD Display AutoRanging Capactiance Meter MESR-100 In Circuit ESR Capacitor Item Description Features: - MESR-100 V2 Auto-ranging capacitor ESR and Low Ohm Meter - Measuring range from 0.001 to 100.0R, support IN CIRCUIT Testing. - Using true 100 KHz sine wave to measure the ESR value, which is equal to the testing method of capacitor manufacturer. - Change square wave to sine wave 100 KHz, reduce square wave’s high frequency component, and affect the reading passing the test leads and capacitor. - Embedded 25V capacitor table at LCD, auto display the capacitor is good or bad reference to common 25V electrolytic capacitor. What is ESR of capacitor? There is a series resistor inside capacitor, using 100kHz to remove the impedance 1/(2*pi*F*C), the impedance become small, and we can then measure the true series resistor value. A bad E-capacitor will have larger ESR and create large ripple rather than filtering noise. Normally, a big capacitor is larger than 3 ohm. Using this theory, we can measure the capacitor is bad/ damaged or good in condition. Because our ESR meter only applies less than 15mV DC or peak to peak on a good capacitor, as a result we can use it as in circuit test. Because this low testing voltage, it cannot turn on the semiconductor inside a circuit under testing. During repairing TV, LCD, Audio board, etc. we can in circuit testing the capacitor is good or not. Note: - Accuracy maybe affected by the test lead’s length and contact point resistance. (Standard test leads is 15cm) - PLEASE DISCHARGE THE CAPACITOR BEFORE TESTING, you can use a screwdriver to short circuit, or series with a resistor around 10 ohm and short for 5 to 10s. There is 2 fast diode inside the meter to prevent high voltage, but it is important to discharge the capacitor firstly, as it is a large surge current and voltage and may damage the meter. Operating Introduction: 1.POWER ON Press and hold the ON/ OFF circle orange button for 2 to 3 second to power on. Press and release the ON/ OFF button to shut down meter. 2.AUTO/ MANUAL Mode: a) Auto Range: Press and release the RANGE button and at the first line of LCD will show “AUTO:" At auto mode meter will automatically select the best range to detect. b)Manual Range: Scroll the manual range from 1R, 10R and 100R range by press and release the RANGE button In LCD will show MANUAL at first LCD line and show at second line: 0-1R, 1-10R and 10-100R. (3)1 Key Zero: Short circuit the test leads’ terminal, cancelling the wire resistance. Press and release the “ZERO" button, LCD shows “ZERO" and wait the zero disappear. If you are using the meter array socket, you need to use a short pin to short circuit to set zero. Backlight: (4) LCD backlight will on during power on (5) Auto Sleep: Around 10 hours for not testing, it will shut down automatically to save power. (6) OVERFLOW or OL: Display overflow when the value is out of range, you can check that you are zero correctly. (7) ESR TABLE: It is for reference only, different manufacturer of capacitor has different ESR, better to test a good cap ESR and compare with what you are testing, usually bad cap with higher ESR few times larger than good one. (8) SOFTWARE ESR: Put the 25V Electrolytic capacitor value to LCD, and compare, GOOD if C < XXuF, means the capacitor maybe good condition if it is less than XXuF 9) PLASTIC STAND: If you don’t use the stand, press and push the lock position: Specification: Range Accuracy (After Zero, tested with 1,10,100R resistor) 0.000 to 1.000R 1%+2Digit 1.000 to 10.00R 1%+1Digit 10.00 to 100.0R 2%+1Digit Accuracy Up to 1% (detail on above table) Wide Measurement Range: >1uF (for 0.1uF the error will be larger on equation 1/(2*pi*F*C) @ 100Khz ) High Resolution 4 digit, or 0.001Ohm @ 1 Ohm range Measuring voltage <~40mV RMS (TESTING VOLTAGE) Clamping voltage ~0.15V (open voltage) Battery 2X AA 1.5V battery External Power 5V micro USB Battery Life time >80 Hours Operating current 0.02A Package Content: 1 X ESR Capacitor 1 X Pair Test Clips Payment Description 1.We accept only PayPal payment. 2.Buyer must pay using PAYPAL ONLY within 7 days from the date of transaction made. Full Payment--Transaction with insufficient payment will not be handled. So, please make you complete the full payment, including Final price + Postage. 3.No Discount--No discount is offered for all transactions. 4.Processing--We will arrange the dispatch within two working days after we receive the valid and completed payment. Shipping Description 1. We ship worldwide except Italy/Turkey/Brazil due to their strict customs tariff policys. 2. Delivery address on Paypal Only--We only ship to the given address in Paypal payment. Please make sure payment address in Paypal is correct. Any non-received items caused by invalid address registered on Paypal are not in our full refund or replacement policy. 3. Shipping Method--Item will be shipped within 2 working days after FULL payment is received. It is noted that Paypal pending payment (such as eCheck) may take up to 5 working days to clear. What we used is Hong Kong air mail post, which may take around 7-23 days to arrive from the date of dispatch issued (This is for USA, CANADA, AUSTRALIA, EUROPE, Asian Countries. For the other countries, it may take more time to arrive). International buyers – Please Note : Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying These charges are normally collected by the delivering freight (shipping) company or when you pick the item up – do not confuse them for additional shipment charges Return Description 1. We supply 1-Years Manufacturer Warranty ( Excluding contrived damagement or misusage). 2. In case of DOA, Please notice us within 3 days and return the case within 14 days after receiving the items. (The date on Post Mark is for standard). After our receiving of the items in good appearance condition, you may have a replacement or refund as long as we cancel the order on ebay(item must be received in 45days), and Shipping cost is non-refundable, as you know shipping & handling was paid to post office. 3. If the item was sent back for repair within 45days, buyer pays for the returning fee. We will be responsible for 2nd shipping cost & handling. 4. If you ask for replacement or repair after two months since you paid, you need to pay for the 2nd shipping cost & handling. 5. If you have to return the item for the refund, you will pay a 20 % restocking fee. 6. In order to provide you the best service, please treat the transaction fairly. Feedback is our life, before you leave a neutral or negative feedback, please DO contact us to get a better solution, Because we don't want to get a NEUTRUAL feedback or NEGATIVE feedback. 7. The address on the parcel is not ours, it is the postman, please DON'T SHIP TO THERE. Please contact with us for the return address before you return it, otherwise we can’t get the parcel you returned. Please contact us for return address before you send. 8.We strive for FIVE STAR Service in our descriptions, communication, shipping speed & costs! We know you have many choices on Ebay, and are most appreciative that you have chosen to shop with us. 9.You can bid and purchase with confidence, as WE are not satisfied until YOU are satisfied with your purchase! If YOU are not satisfied, please let us know so we can make it right. 10.Please email me through ebay "MY MESSAGES" if you have any questions about our listings or inventory! About Us 1. Please don't hesitate to contact us with any queries or comments about our items or your problem. 2. Please note that we are open Monday to Friday between 09:00 Am to 06:00 PM Beijing Time, which means we can keep on-line at: Your partner for managing your online business
