New Digital Portable Rf Power Meter Tester Ry-r50 50mhz Gsm Cdma Phs

US $586.00

Wenzhou, ZJ, China
Jan 29th

Open on mobile:
QR code

RF Power Meter RY-R50 1.Introduction: The product is a High-frequency power meter having good performance and carried conveniently, especially designed for measuring complex waveform. The application of measuring Digital-communication signal such as GSM, CDMA, PHS, resolves effectively the problem of measuring complex waveforms power and amplitude, which makes the meters reliability higher. The human design style used on operating methods and display accords with the operators habit. The products low price makes the connection with dear equipments little stronger, and is fit for measure and maintenance in wireless communication. 2.Specification: Absorb mode parameter Input channel single channel Dynamic range >40dB Measure mode Manual, Auto(Recommend) Frequency range 2-2000MHz, 2-3000MHz Amplitude range 40dBm,+5dBm -10dBm,+35dBm (30dB) 0dBm,+45dBm (40dB) Resolution 0.01dB Measure precision +-0.3dB Input signal GSM, CDMA, PHS and so on Input impedance 50Ohm Through mode parameter Frequency range 800-2500MHz Amplitude range +13dBm--+53dBm 50Ohm standing -wave ratio in reference <1.1 Insert wastage <0.4dB Input impedance 50Ohm Probe wave <1.2 Others Display screen TFT LCD(320*240) Battery 7.2V lithium battery Work time average>24 hours ,series>12 hours Power adapter 100-240V/0.8A 50-60Hz Charge time about 5 hours Volume 240 (L)100*(W)50*(H)mm Weight 0.7 kilograms Storage temperature -10--+40oC Storage environment put in dry condition Display interface Calibration parameters of frequency range in communication used frequently are considered when designed, which makes your work simply. Ordering Information Name Model Describe Portable Power Meter RY-R50 (50MHz) Power range: -45dBm--+15dBm Auto measure Manual calibration, accuracy is +2dB; Internal rechargeable battery, last for 12 hours External power sensor, make the measure easier Optional attenuator can make high power measure Table model fit laboratory environments use Portable Power Meter RY-R2000(2~2000MHz) RY-3000 (2~3000MHz) Directional Power Meter RY5000D- (800~2500MHz) Make power and standing wave measurement Power range: 25mW~200W. 3.Payment: We accept the following forms of payment 4.Shipping: We will ship all items within 1-3 working days upon receipt of payment,our goal is: ship it as fast as we can. Expedited/Standard Int'l Shipping by Fedex,UPS,TNT and EMS courier: To USA,need 3-6 business days,To other countries,need 4-8 business days normally.But sometimes int'l delivery is highly depended on the courier company and local customs/duties. Import duties and taxes are not included in the item price or shipping charges.These charges are the buyer responsibility. 5.Warranty&Reture Policy: We encourage all customers to communicate with us through eBay messages. If you have any questions or comments whatsoever regarding our products or listing, we are waiting to hear from you A 1 year warranty is offered for this product.If the product malfunctioned under proper usage per instructions manual within the warranty period, please contact us to obtain shipping instructions and send it back at your shipping costs. 30 days evaluation and investigation takes placed after receiving your return item.A brand new replacement unit will be sent to you at our shipping costs if it meets our warranty requirements. Welcome to my store--http://stores.shop.ebay.com/sparkerinstruments Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
