New Atc Series 328 Time Delay Relay 328d 200 F10 Xx

US $69.00

Rochester, New York, United States
Mar 5th

Open on mobile:
QR code

You are bidding on a New Automatic Timing & Controls Series 328 Time Delay Relay, No.328D 200 F10 XX with 11 blade base. VOLTAGE & FREQUENCY - 24VAC to 240VAC and 24VDC An extremely versatile dial-adjustable time delay relay, the ATC 328 provides a choice of ON-Delay, OFF-Delay or interval operation for any timing period between 50 ms and 10 hours...all in the same timer. Based on a unique digital circuit, it features cycle progress annunciation and is suitable for the most demanding industrial service. PRODUCT HIGHLIGHTS DESIGNED FOR INDUSTRIAL SERVICE With a load relay that is rated for 100,000,000 mechanical operations, and power supply that protects circuit components against the voltage transients that are typical of industrial plants,the 328 has a long life expectancy even in tough environments. CYCLE PROGRESS INDICATION The 328’s LED annunciator provides a unique and extremely effective method of cycle progress indication. Off before timing, the LED blinks at an ever-increasing rate as the cycle progresses: once every 3 1/2 seconds during the first 10% of the cycle, twice during the second 10%, and so on. At time-out, the LED stays on constantly, pulsing at a high rate. (In the 1 and 10-second ranges, the LED is off before timing, steady on during timing, and pulsing on after time-out.) VERSATILE MOUNTING The standard 328 has an 11-pin base which accepts push-on connectors or plugs into a surface-mounted socket. Since all connections are made to the socket, the 328 is readily removed without disturbing the wiring. It is also available with an optional quick-connect plug and brackets for flush panel-mounting. MULTIPLE RANGES REDUCE INVENTORY REQUIREMENTS Because the 328 has six switch-selected ranges--from 1 sec to 10 hours--each timer can provide any dial-adjustable timing period between 50 ms and 10 hours...thus greatly reducing inventory requirements especially for large users. The range selector switch knob can be easily removed to prevent unauthorized range change. HIGH ACCURACY The 328’s digital circuit maintains rated accuracy from cycle to cycle, regardless of reset time variations. Its oscillator-based circuit is also effectively compensated for changes in temperature and voltage and thus achieves excellent overall accuracy. VERSATILE CONTROL CAPABILITY Every 328 can be used for either On-Delay, Off-Delay or interval operation, depending on how its terminal block is wired. For more Information see: http://www.anderson-bolds.com/Merchant2/graphics/00000001/timers/atc/pdfs/328D_data.pdf I will fully guarantee this timer - "Proudly Made in the USA". Shipping in the Continental USA is $7.90 - I have very competitive rates for International bidders that are always welcome. Thanks for looking! If you have any question on this item please call us at 1-800-826-3433 (9 - 5pm Eastern). Pay me securely with your Visa or MasterCard through PayPal! Powered by SixBit's eCommerce Solution

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	MPN	328D 200 F10 XX
MANUFACTURER	ATC
Type	Timer
