Ne555 Pulse Frequency Duty Cycle Square Rectangular Wave Signal Generat Racg

C $2.47

Shanghai, China
May 18th

Open on mobile:
QR code

Description Description&Previewshipping&policy NE555 Pulse Frequency Duty Cycle Square Rectangular Wave Signal Generat Racg DESCRIPTION: Description: 100% brand new and high quality Module Scope: -Used as a square wave signal generator produces a square wave signal for the experimental development use. -Used to generate the square wave signal to drive a stepper motor drive. -Produce adjustable pulse for the MCU to ue. -Generating adjustable pulse to control the associated circuits. Features: -Size: 2.8CM * 3.6CM -The main chip: NE555; -Input voltage: 5V-15VDC. 5V power supply, the output current can about 15MA; 12V power supply, the output current can be so 35MA; -Input Current: ? 100MA -Output amplitude: 4.2V V-PP to 11.4V V-PP (depending on the input voltage, the output amplitude is not the same) -Maximum output current:? 15MA (5V power supply, V-PP greater than 50%), ? 35MA (12V power supply, V-PP greater than 50%) Advantages: -Output with LED indication, there is no output LED quantity (low straightforward, high level LED off relatively low frequency LED flashes); -Output frequency range grade optional continuously adjustable output frequency; -Low-frequency stall: 1Hz ~ 50Hz -IF stall: 50Hz ~ 1kHz -In the high-frequency stall: 1KHz ~ 10kHz -High-frequency stall: 10kHz ~ 200kHz -the output duty cycle can fine-tune the duty cycle and frequency is not adjustable separately adjust the duty cycle will change the frequency -the output frequency is adjustable; -Cycle T = 0.7*(Ra + 2*Rb)*C -Ra, Rb:0-10K adjustable; -LF gear C = 0.001UF; -IF file C = 0.1UF; -In the high-frequency file C = 1UF;, -High-frequency gear C = 100UF, the waveform frequency buyers can own calculations. NOTE:Output duty cycle can fine-tune the duty cycle and frequency is not adjustable separately adjust the duty cycle will change the frequency Package Included: 1PCS X NE555 Duty Cycle and Frequency Adjustable Module Square Wave Preview: Thank you for your purchase Problems? You can follow below process to chontact us. There is a time zone difference,but we will do our best to quickly response to your questions: Shipping We will arrange shipping for you within 2-5 days after payment cleared except the holidays. We always send the item to the address you give us on PAYPAL to ensure the security of the item. If you have changed your address, or want us to ship to another address, please change to the new address when you pay us with PAYPAL, otherwise we will not be responsible if the package is lost. Payments We accepts Paypal only If you have any questions about the payment,please contact us through eBay message. Import Duties In case some duty is due Upon delivery, it is your responsibility to meet that expense and this may cause delays to delivery schedule and you may have to pickup goods at the customs office. Terms & Conditions By bidding on this item,the Buyer agrees to all of the terms and conditions as outlined in this listing .please ensure to read and agree to All eBay terms and Conditions before bidding. All pictures are for illustration purpose only and Colours may vary slightly. Our store obeys all eBay Rules and Policies. Returns Policy To Return an item you must contact us and take photos of your item to clearly show any damage or unusual aspects of it. Approved returns will be subject to inspection on arrival. Items must be returned in original condition with all original packaging. All shipping and handing charges are non-refundable Return delivery costs are the responsibility of the buyer. We will cover the cost if sending replacement/repaired items. Within 7 days after receiving your products, we offers a no-hassle 7 day exchange/replace only if your items are found to be defective by manufacturer.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
UPC	Does not apply
MPN	Does not apply
Manufacturer Part Number	Does not apply
Brand	Unbranded
Type	//
GTIN	Does not apply
Model	//
