Multicam 3000 Series Cnc Waterjet (2011)

US $20000

Battle Creek, Michigan, United States
Jun 24th

Open on mobile:
QR code

GENERAL SPECIFICATIONS CAPACITY: X-AXIS TRAVEL 120" Y-AXIS TRAVEL 60" Z-AXIS TRAVEL 8" INTENSIFIER PUMP OUTPUT 90,000 PSI INTENSIFIER PUMP MOTOR 60 HP RAPID TRAVERSE SPEED 1400 IPM REPEATABILITY 0.001" APPROXIMATE DIMENSIONS 13'8" X 8'2" EQUIPPED WITH: MULTICAM EZ CONTROL W/EZ SUITE SOFTWARE KMT 60 HP DUAL INTENSIFIER PUMP BRUSHLESS DIGITAL AC SERVO DRIVES EBCO CLOSED LOOP SYSTEM ABRASIVE HOPPER Z-AXIS CLEARANCE 10” Z-AXIS TRAVEL 8” RESOLUTION: .0001” REPEATABILITY: +/- .001” POSITIONAL DISPLACEMENT ACCURACY: +/- .005” OVER 10 FEET RAPID TRAVERSE: 1400 IPM MAXIMUM CUTTING SPEED; 1500 IPM DRIVES: BRUSHLESS DIGITAL AC SERVO DRIVE SYSTEM X AND Y-AXIS: LINEAR RACK AND PINION DRIVE SYSTEM Z-AXIS: PRECISION BALL SCREW 3000 SERIES WATERJET STANDARD FEATURES NO MACHINE OFFERS MORE STANDARD FEATURES THAN THE MULTICAM ALL STEEL, STRESS RELIEVED, INTEGRAL WATER TANK DESIGN THREE (3) SIDE CUTTING TANK ACCESS FOR EASY LOAD AND UNLOAD INTEGRATED FORK LIFT TUBES FOR EASY MACHINE POSITIONING AND INCREASED MACHINE RIGIDITY HEAVY C CHANNEL GUTTERING FOR WATER RUN-OFF AND EXCEPTIONAL UPPER MACHINE RIGIDITY MOVING GANTRY WITH DUAL SIDE, BRUSHLESS DIGITAL AC FULL 360 DEGREE BELLOWS ON ALL AXES FAST SWITCHING BETWEEN PURE WATER AND ABRASIVE CUTTING WEIR SETTLING TANK AND SUMP PUMP MULTICAM EZ CONTROL AND EZ SUITE SOFTWARE INTEGRATED PC WITH 19” LCD MONITOR STANDARD ETHERNET INTERFACE WITH DNC FILE SYSTEM AND UNLIMITED FILE SIZE TRANSFER CAPABILITIES NC GEOMATE SOFTWARE STANDARD SPECIFICATIONS ARE SUBJECT TO BUYER VERIFICATION
