Quality Liquidators Moving Pixel Company IQAWG-A Arbitrary Waveform Generator ++ About the Item The Moving Pixel Company IQAWG-A I/Q Arbitrary Waveform Generator This auction is for a Moving Pixel Company IQAWG-A Arbitrary Waveform Generator. This was purchased from a local lab in good working condition. Comes as pictured with Control breakout cable and power cable, no software or manuals available. This has the following options installed 64MB Flash, IF70 and BER. Description: The I/Q Arbitrary Waveform Generator (IQAWG-A) is a versatile device for storing and playing out/looping arbitrary data streams to generate twin analog outputs, I and Q, for quadrature modulated systems. It adds the unique capability of adding Additive White Gaussian Noise (AWGN) to each output I and Q. The AWGN data is not stored with the IQ data but algorithmically generated in real-time. This keeps the noise from always hitting the same bit (what happens in a conventional AWG). The noise added to each channel is statistically independent. The noise is added digitally after all other stream generation functions and has a flat frequency spectrum (white). The noise source runs through the same DACs that produce the signal so that Eb/N0 is constant and does not require calibration for a given setup. The IQAWG has the further capability of combining both stored and algorithmically generated data. For example, if it was desired to generate a triangle wave with PN15 noise added, the IQAWG could produce the triangle and noise data algorithmically, using no internal storage of a waveform. This allows simple algorithms that do not repeat (in a short amount of time/memory) to be produced by the generator. The IQAWG was developed specifically for the production test environment. However, the accompanying PC software makes it very easy to use in an engineering environment. Design features driven by the production environment include: pattern storage in Flash memory (no reboot time), rear panel connectivity for signals and control, 19 inch rack mount, and very deep memory (up to 512 MB Flash, equivalent to 16 GB in most AWGs). This amount of memory translates into about 5 1/2 minutes of DSS video. Code modules that exist for the IQAWG include PN15, DSS (DirecTV) signal format, DVB signal format, ATSC signal format, DVB-S2 inclcuding ACM and Hierarchical modes, rate 1/2, 2/3, 3/4, 4/5, 5/6, 6/7, 7/8, 8/9, and rate 9/10 convolutional encoding, DSS/DVB interleaving, ATSC interleaving, FSK2, FSK3, FSK4, BPSK, QPSK, OQPSK, SQPSK, 8-VSB, 8-PSK, and QAM4-QAM256. The IQAWG-A also has the capability measuring the Bit Error Rate (BER) of a receiving unit under test. To test BER, a user simply sets the IQAWG to generate and modulate a PN stream then returns the demodulated data from the unit under test. The number of bits received is tabulated against the number of errors received over the same period and returned to the GUI for display. The interval for the test is specified via the GUI by the user. The IQAWG was designed to operate with the Rohde & Schward SMIQ signal generator; it will work with others. An optional (included with the product) PC-based GUI requires a Windows 98/NT/W2K/ME/XP PC with bidirectional printer port (EPP) capability. A .dll is also included for IQAWG control from within a user-control program. TMPC works with customers to configure the box for their base signal modulation format. IQAWG-A Product Information Maximum symbol rate 45 MSPS (variable from 1.0MSPS to 45MSPS in 0.5 MSPS steps) AWGN repeat time approx 2^126 seconds AWGN range QPSK Eb/N0 from 0.0dB to 9.9dB, Crest Factor: 13.5 dB AWGN -3dB bandwidth 25 MHz DAC rate 90 MHz, max. (multiple fixed frequencies available) DAC resolution 10 bits (12, 14 available) I/Q output impedance 50 ohms I/Q levels Combined level root-sum-of-squares 0.35Vp. Each component 0.2475 Vp I/Q coupling DC Power: 100 - 240 Volts, Universal, less than 15 watts Mechanical: 1 Rack Unit high, compatible with 19" rack Connectors and Controls: TTL level rate select via DB25 female on the back panel. Power via universal connector on the back panel. I and Q via BNC on the back panel. Maintenance connector (DB25M) on the back panel. Noise/ Eb/N0 Adjust via software configuration. Prices subject to change without notice. Prices good as of January 2005. Description Part Number List Price IQAWG with 64 MB Flash IQAWG-A-64M-X $ 18,700.00 Items are sold "As-Is" unless otherwise stated. I am not familiar with all of the products I list and I do not have the time or ability to completely test each one. I will list what information I have and the condition of the item to the best of my ability. Items are in used condition unless otherwise stated. This means that items may or may not have scratches, dings, dents, scuffs, marks, cracks, scrapes, discoloration, dust, dirt or other conditions related to use and or transport. I will attempt to note any major damage in the listing. There are no warranties or guarantees unless specifically stated in the listing. Seller is not responsible for errors in the technical description of item. Model numbers are provided with equipment and the buyer will be responsible for knowing the capabilities of equipment. Items do not come with documentation, drivers, cords, keys, attachments, accessories, consumables or support unless stated in the listing. Thank you and happy bidding About Payment and Shipping Buyer pays $20.00 shipping, insurance, and handling to anywhere within the Continental US. After purchasing, Pay instantly with your credit card through PayPal! About the Seller Please see my other auctions here: Other Auctions Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
