Motorola Cyclone Equipment, US $210 – Picture 0
Motorola Cyclone Equipment, US $210 – Picture 0

Motorola Cyclone Equipment

US $210

  • Ontario, California, United States
  • Jun 9th
Open on mobile:
QR code
Antenna Specifications: Cyclone 5250-120 Polarization: Vertical Gain, dbi (nominal) Beamwidth -3dB: 11.7 Horizontal Plane Beamwidth: 120° Vertical Beamwidth -3 db: 8 X-Polarization Rejection: >25 dB Front to Back: 25dB VSWR: 1.5 Maximum Model # : CY-5V-120-14NM Antenna Specifications Radio Specifications: Frequency, GHz: 5.250-5.350 UNII Access Mode: TDD/TDMA Signaling Rate: 20Mbps Carrier to Interference: 3dB nominal, with receiver input @ –65 dBm and higher. Receiver Sensitivity: –83 dBm 10–4 BER Operating Range: Up to 4 miles Output EIRP: 30dBm DC Power: 0.30 Amp @ 24 VDC (7.2 watts) Interface: 10/100 BaseT, Half/Full Duplex rate auto negotiated. Protocols used by Cyclone: IPV4, UDP, TCP,ICMP,Telnet, HTTP, FTP, SNMP, AES   Protocols supported by Cyclone: Switched Layer 2 Transport w/support for all common Ethernet protocols including IPV6, NetBIOS, DHCP, IPX, Etc. Software Upgrade Path: Remotely Downloaded into Flash via RF link Network Management: HTTP, TELNET, FTP,SNMP Version 2C Temperature: –40° C to +55° C (–40° F ~ 131° F) Weight: 9 lbs. Dimensions: Length 30", Width 4", Depth 10" FCC/IC Certification: QSX5200ISM / 4586A-5700EC Wind Loading Specifications:  217.09 Lbs.@140 M.P.H. The Cyclone Mount is designed for flexibility and dependability. All components are custom machined from Aircraft Grade Anodized Aluminum and High Quality 304 Stainless Steel in order to create the most durable product possible. Our Mount is designed to accommodate mounting surfaces up to 3.5” in diameter and allows for greater than 15° of Downtilt as well as 4° of Uptilt. Additionally in the last picture for this set you can see a small hole in one of the antennas. It was operational at the time it was taken down, so it does not appear to be service affecting. Please note the following statements and understand that this set is being sold as is.  ***We are not offering any warranties.***  ***No exchanges or refunds.***
