Module, Output, 2 Channel, Relay 2 No, 230 Vac, 30 Vdc, (wago #750-513)

US $17.75

Albuquerque, New Mexico, United States
Jan 29th

Open on mobile:
QR code

Module, Output, 2 Channel, Relay 2 NO / Potential Free, AC 230 V, DC 30 V, Wago Wago #750-513 The WAGO I/O SYSTEM 750 SYSTEM DESCRIPTION The WAGO I/O SYSTEM 750 is a modular, fieldbus independent I/O system. It is comprised of a fieldbus coupler/controller and connected fieldbus modules for any type of signal. Together, these make up the fieldbus node. The end module completes the node. Couplers/controllers for fieldbus systems such as PROFIBUS, INTERBUS, ETHERNET TCP/IP, CAN (CANopen, DeviceNet, CAL), MODBUS, LON and others are available. The coupler/controller contains the fieldbus interface, electronics and a power supply terminal. The fieldbus interface forms the physical interface to the relevant fieldbus. The electronics process the data of the bus modules and make it available for the fieldbus communication. The 24 V system supply and the 24 V field supply are fed in via the integrated power supply terminal. The fieldbus coupler communicates via the relevantfieldbus. The programmable fieldbus controller (PFC) enables the implementation of additional PLC functions. Programming is done with the WAGO-I/O-PRO 32 in accordance with IEC 61131-3. Bus modules for diverse digital and analog I/O functions as well as special functions can be connected to the coupler/controller. The communication between the coupler/controller and the bus modules is carried out via an internal bus. The WAGO-I/O-SYSTEM 750 has a clear port level with LEDs for status indication, insertable mini WSB markers and pullout group marker carriers. The 3-wire technology supplemented by a ground wire connection allows for direct sensor/actuator wiring. MODULE DESCRIPTION The connected load is switched via the digital output (relay contacts) from the control system. The module has two output channels. Two actuators with ground (earth) wire may be directly connected to signal output DO 1 and N signal output DO 2 and N. The module has two make contact relay , i.e. only the connection points of the relay contacts are on the fieldside so that both sets of contacts can be connected to different voltages independent from each other. Due to the isolated contacts, it is also possible, for example, to connect both relays in series or several relays can be connected in series by grouping these modules. The relay contacts L1 and L2 are supplied with 230 V AC or 30 V DC external voltage. By closing a relay, the power applied to L1 or L2 is switched to the second relay connection DO1 or DO2. The internal system voltage is used to trigger the relays. The switching status of the two relays is indicated via green status LEDs. Any configuration of the output modulesis possible when designing the fieldbus node. Grouping of module types is not necessary. Attention: The standard output module has only one built-in power jumper contact for the ground and the version 750-513/000-001 has no power jumper contacts. For field supply to downstream I/O modules, a supply module will be needed. Warning: The maximum current of the internal power jumper contacts is 10 A. When configuring the system it is important not to exceed the maximum/sum current. However, if such a case should occur, another supply module must be added. Note: For the protection of relay coils and contacts, inductive loads must be dampened with an effective protection circuit! Examples of protection circuits can be seen in the section 2.1.2"Contact Protective Circuit for Relay Modules". The output module 750-513 and its variations can be used with all couplers/controllers of the WAGO-I/O-SYSTEM 750. MODULE FEATURES Control signals are transmitted from the automation device to connected actuators via the digital output module. The internal system voltage is used to trigger the relay. The NO contacts are electrically isolated. The switched status of the relay is shown by an LED. Actuators with a ground (earth) wire may be directly connected to the module. Switching power: 500 VA / 60 W (resistive load) cos j max. =0.4; L/R max = 7 ms Isolation: 1.5 kV eff. (field/system)*; * 2.5 kV rated surge voltage; Overvoltage category III Electrical life (min.): 3 x 105 switching operations (2 A / 250 V AC) or (2 A / 30 V DC) MODULE SPECIFICATIONS: Color: Light Gray Conformity Marking: CE No. of Outputs: 2 Make Contacts Current Via Power Jumper Contacts (Max.): DC10A Max. Current Consumption (Internal) [mA]: 100 mA Max. Switching Voltage: 250 VAC / 30 VDC Min. Switching Current: 10 mA / 5 VDC Max. Switching Current: 2A AC/DC Max. Switching Frequency: 30/min (at Nominal Load) Pull-In Time (Max.): 10ms Bounce Time (Typ.): 1.2ms Drop-Out Time (Max.): 10ms Contact Material: Silver Alloy Mechanical Life (min.): 2 x 107 Switching Operations Internal Bit Width: 2 Bits Degree of Pollution: II; acc. to IEC 61131-2 Voltage Drop at I Max: <1V Degree of Protection: IP20 Data Contacts: Gleitkontakte, hartvergoldet, 1,5µm, selbstreinigend Power Jumper Contacts: Messer-/Federkontakt, selbstreinigend Clearances and Creepage Distances: gem. IEC 60664-1 Connection Technology (1): CAGE CLAMP® Cross Section: From (1) 0.08 mm? to 2.5 mm? Cross Section: From (1) 28AWG to 14 AWG Stripped length from (1) 8mm up to 9 mm Stripped length (1) 0.33 in Fire Load: 1.284 MJ Weight: 53.5g [g] Width: 12mm / 0.472 in. Height: 64 mm/ 2.52 in Length: 100mm / 3.937 in Storage Temperature: -25° C ... +85° C Relative Air Humidity (No Condensation): 95% Type of Mounting: DIN 35 Rail Operating Temperature: 0°C ... +55°C Mounting Position: Any Exposure to Pollutants: gem. IEC 60068-2-42 und IEC 60068-2-43 EMC: Marine Applications - Emission of Interference: acc. to Germanischer Lloyd (2003) EMC: Marine Applications - Immunity to Interference: acc. to Germanischer Lloyd (2003) EMC: CE - Emission of Interference: acc. to EN 61000-6-4 (2007) EMC: CE - Immunity to Interference: acc. to EN 61000-6-2 (2005) Housing Material: Polycarbonat, Polyamid 6.6 Maximum Pollutant Concentration With A Relative Humidity <7: SO2

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Wago
Country/Region of Manufacture	Germany
MPN	750-513
