Mk-168 Transistor Tester \ Rlc Meter \ Esr Meter

US $35.00

  • ???, ???, China
  • Jan 29th
MK-168 transistor tester \ RLC meter \ ESR meter     Description: 1,2013 latest M328 version of the software ,more functions. 2,Use 8MHz external crystal , better measurement accuracy. 3.Backlight LCD display,only 2mA when stand by. 4,Mainchip is the DIP, easy to DIY, update the mainchip . 5,Using 9V battery. Specifications: 1,One -button operation, automatic shutdown . 2,Only 20nA shutdown current. 3,Automatically detect NPN, PNP bipolar transistors , N -channel and P -channel MOS FET, JFET , diodes , two diodes, thyristors small power unidirectional and bidirectional thyristor. 4,Automatic identification components pin arrangement . 5,Measuring bipolar transistor current amplification factor and base - emitter threshold voltage. 6,Via the base - emitter threshold voltage and high current amplification factor to identify Darlington transistors. 7,Can detect bipolar transistors and MOS transistors protection diodes. 8,Measuring the gate MOS FET threshold voltage and the gate capacitance. 9,Can simultaneously measure two resistors and resistor symbol is displayed. Displayed on the right with a decimal value of 4 . Resistance symbol on both sides shows the pin number. So you can measure the potentiometer. If the potentiometer wiper is not transferred to an extreme position , we can distinguish the middle and both ends of the pin. 10,Resistance measurement resolution is 0.1 ohms , 50M ohms can be measured . 11,Can measure capacitanceCan measure capacitance of 30pF-100mF , resolution 1pF. 12.2uF more capacitors can simultaneously measure the equivalent series resistance ESR values. The two can be displayed with a decimal value , resolution 0.01 ohms. 13,Can be in the correct order and the diode symbol display two diodes , and gives the diode forward voltage. 14.LED is detected as a diode forward voltage higher . Combo of the LED is identified as two diodes. 15,Eeverse breakdown voltage is less than 4.5V Zener diode can be identified. 16,Can measure a single diode reverse capacitance. If the bipolar transistor connected to the base and collector or emitter of a pin , it can measure the collector or emitter junction reverse capacitance . 18 can be obtained with a single measurement rectifier bridge connection. Notice: Before measuring capacitance , the capacitor must be discharged , otherwise very likely damage the meter .     Package including   1 x esr meter      Payment We accept the payment via PayPal only. Payment is expected within 5 days of the auction's end. Availability of the item can not be guaranteed if no payment received in 3 days. Please don't purchase if you are not intend to pay. Unpaid item will report to eBay and get the warning. .   Shipping & Handling   1.Items are shipped from china.we will send out within 2 working days after receive the money.   2.We usually send the parcel by Singapore Post Air Mail or HongKong Post Air Mail. After send out,most country will arrived the parcel in 12-25 business days. We also can provide Express,such as Fedex,DHL,EMS,usually 3-7days to most country.If you need Expedited shipping,contact us. The global shipping is difficult to control sometimes,if you havent receive after 25days,contact us,we will check for you. 3.We send to the address of ebay add info,please check your add info of ebay is correct.   4.Some conutries,such as Italy,Brazil,we can ship to,but it usually needs more than 30days to arrive,if you dont care the long time of shipping,contact us.   Warranty and Return  1.If you are not satisfied when you receive your item, please return it within 14 days for a replacement or money back. Please contact us before you return it.   2.If item is defective in 14 days, We will send you a replacement without extra charger, or offer refund after we receive the defective item.   3.If item is defective after 14 days, you can still send it back to us. We will send you a new one after receiving the defective item. But you have to pay the extra shipping free.                                                                Feedback please leave behind your positive feedback for us after you receive the item, no matter whether you are satisfactory with my item, we will leave behind the same to you. If you want to leave a negative feedback,please contact me at first, we trust that everything could be issued before you leave it. Contact us We work 6 days except Sunday and public holidays. Please feel free to contact us anytime if you have any questions , We will try our best to help you.
