Micro Sd Storage Board Mciro Sd Tf Card Memory Shield Module Spi For Arduino C

US $70

  • ShenZhen, China
  • May 24th
Home Electronic Component Chips Sensor Arduino Module Raspberry Pi Micro SD Storage Board Mciro SD TF Card Memory Shield Module SPI For Arduino C   Specification: The module (MicroSD Card Adapter) is a Micro SD card reader module, and the SPI interface via the file system driver, microcontroller system to complete the MicroSD card read and write files. Arduino users can directly use the Arduino IDE comes with an SD card to complete the library card initialization and read-write Module features are as follows: 1 Support Micro SD Card, Micro SDHC card (high-speed card) 2 the level conversion circuit board that can interface level is 5V or 3.3V 3 power supply is 4.5V ~ 5.5V, 3.3V voltage regulator circuit board 4. Communication interface is a standard SPI interface 5. 4 M2 screw positioning holes for easy installation Control Interface: A total of six pins (GND, VCC, MISO, MOSI, SCK, CS), GND to ground, VCC is the power supply, MISO, MOSI, SCK is the SPI bus, CS is the chip select signal pin; 3.3V regulator circuit: LDO regulator output 3.3V as level converter chip, Micro SD card supply; Level conversion circuit: Micro SD card into the direction of signals into 3.3V, MicroSD card toward the direction of the control interface MISO signal is also converted to 3.3V, general AVR microcontroller system can read the signal; Micro SD card connector: yes since the bomb deck for easy card insertion and removal. Positioning holes: 4 M2 screws positioning hole diameter of 2.2mm, the module is easy to install positioning, to achieve inter-module combination;       Shipping Included: 1PCS*Micor SD TF Card Shield Expansion Board for Arduino DIY Payment Shipping Refund We accept PayPal only. But we only Accept your Ebay Address,Please Make sure it's 100% right. Payment must be received in 5 business days of auction closing. Please leave note for your special request (e.g. Colors or Size) in PayPal when you pay the order. Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched. We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns.   All package need to wait 30 days(US only need 7-10 days),Please take care it.Less than 30 days,we can't take a refund. If the item is defect when you receive it or you are not satisfied with it, please return it within 14 days for a replacement or money back. But the items must be back in factory condition. Please contact us and double check the return address before you return it. If is item is defective in 12 months, you can return it to us. We will send you a new replacement after receiving the defective item.
