Mesr-100 V2 Esr/low Ohm In Circuit Test Capacitor Meter Include Smd Clip Probe

US $67.99

shanghai, China
Jan 29th

Open on mobile:
QR code

MESR-100 V2 ESR/LOW Ohm In Circuit testing Capacitor meter include SMD Clip Probe with LCD Display Features: JINGYAN MESR-100 V2 Auto-ranging capacitor ESR and Low Ohm Meter Measuring range from 0.001 to 100.0R, support IN CIRCUIT Testing. Using true 100 KHz sine wave to measure the ESR value, which is equal to the testing method of capacitor manufacturer. In the market, there is some technique using short pulse method to testing, but the value will be varying vs the capacitance and sometimes reading is different from the manufacturer's value. What is ESR of capacitor? There is a series resistor inside capacitor, using 100kHz to remove the impedance 1/(2*pi*F*C), the impedance become small, and we can then measure the true series resistor value. A bad E-capacitor will have larger ESR and create large ripple rather than filtering noise. Normally, a big capacitor is larger than 3 ohm. Using this theory, we can measure the capacitor is bad/ damaged or good in condition. Because our ESR meter only applies less than 15mV DC or peak to peak on a good capacitor, as a result we can use it as in circuit test. Because this low testing voltage, it cannot turn on the semiconductor inside a circuit under testing. During repairing TV, LCD, Audio board, etc. we can in circuit testing the capacitor is good or not. *Dual terminal, for fast and easy inspect general capacitor or resistor, a printed ESR table for fast check Compare MESR100 old V1 and new V2 Improvement: 1) Change square wave to sine wave 100 KHz, reduce square wave’s high frequency component, and affect the reading passing the test leads and capacitor. 2) Higher Resolution up to 0.001 ohm. 3) 128X64 dot matrix LCD, with more larger value display and information 4) Embedded 25V capacitor table at LCD, auto display the capacitor is good or bad reference to common 25V electrolytic capacitor. 5) New plastic case, curve design for hand carrying. New stand for 60 degree stand on desk. 6) Use 2X AA battery, more convenience and longer battery life than 9V battery. 7) Support external USB power, using standard micro-USB port. Specification: Range Accuracy (After Zero, tested with 1,10,100R resistor) Refresh Time (Manual Mode) *Auto mode take 0 to 2s more time depend on value 0.000 to 1.000R 1%+2Digit ~0.4s 1.000 to 10.00R 1%+1Digit ~0.4s 10.00 to 100.0R 2%+1Digit ~0.4s *Accuracy maybe affected by the test lead’s length and contact point resistance. Standard test leads is 15cm, for longer test leads need special shielding to affect the EMI inference (Can contact sales’ person for more detail) 1) Accuracy: Up to 1% (detail on above table) Wide Measurement Range: >1uF (for 0.1uF the error will be larger on equation 1/(2*pi*F*C) @ 100Khz ) 2) High Resolution: 4 digit, or 0.001Ohm @ 1 Ohm range 3) Measuring voltage: <~40mV RMS (TESTING VOLTAGE) 4) Clamping voltage: ~0.15V (open voltage) 5) Battery 2X AA 1.5V battery 6) External Power: 5V micro USB 7) Operating current 0.02A 8) Battery Life time: >80 Hours Operating Introduction: 1) POWER ON Press and hold the ON/ OFF circle orange button for 2 to 3 second to power on. Press and release the ON/ OFF button to shut down meter. 2) AUTO/ MANUAL mode: i) Auto Range: Press and release the RANGE button and at the first line of LCD will show “AUTO:" At auto mode meter will automatically select the best range to detect. ii) Manual Range: Scroll the manual range from 1R, 10R and 100R range by press and release the RANGE button In LCD will show MANUAL at first LCD line and show at second line: 0-1R, 1-10R and 10-100R. 3) 1 Key Zero: Short circuit the test leads’ terminal, cancelling the wire resistance. Press and release the “ZERO" button, LCD shows “ZERO" and wait the zero disappear. If you are using the meter array socket, you need to use a short pin to short circuit to set zero. 4) Backlight: LCD backlight will on during power on 5) Auto Sleep: Around 10 hours for not testing, it will shut down automatically to save power. 6) OVERFLOW or OL: Display overflow when the value is out of range, you can check that you are zero correctly. 7) ESR TABLE: It is for reference only, different manufacturer of capacitor has different ESR, better to test a good cap ESR and compare with what you are testing, usually bad cap with higher ESR few times larger than good one. 8) SOFTWARE ESR: Put the 25V Electrolytic capacitor value to LCD, and compare, GOOD if C < XXuF, means the capacitor maybe good condition if it is less than XXuF 9) PLASTIC STAND: If you don’t use the stand, press and push the lock position: Package include: 1 PCS MESR-100 V2 meter(no including batteries in the package!!!) 1 pair test probe 1 PCS SMD clip probe Please note: If the item is urgent for you, please choose "Expedited shipping"! Shipping Summary: Once your payment is clear, we will send the item out within 3 business days. Free shipping: Registered China Post Air Mail or ePacket (with tracking number) Expedited shipping: DHL, UPS, EMS or others Shipping Details: Free shipping: We will send via Registered China Post Air Mail to the worldwide. (For USA, UK and Australian customer, we will send the item via China Post ePacket, it takes about 7-15 business days to deliver in normal condition, you can directly track the shipping information in eBay system) After shipping, we will provide the tracking number and you can check the updated shipping information in 3 business days by clicking the following link: intmail.11185.cn/itemtrace_en.jsp (China Post Air Mail) (please note: sometimes, specially during the shopping seasons or long holidays, shipping information may be updated slowly because post office workers spend more time on the huge backlog of parcels. We appreciate your patience) In normal condition, it takes 10-25 business days (no including weekends or holiday) to reach you. Thank you for your waiting! Expedited shipping: We will send DHL, UPS, EMS or other express. We will provide the proper shipping way according to different countries. For example, in most cases, we will provide DHL or UPS for European countries. For neighbor countries, such as Russia federation, Ukraine, Belarus, Kazakhstan, we will provide EMS. In normal condition, it takes about one or two weeks to deliver. Different country has a different Customs policy. You can contact us at any time if you have any problem or some special requirements . We will reply to you As Soon As Possible! Communication & Feedback At first, we appreciate every customer feedback. We would be very grateful if you can give us some advice on our products. If you have any complaints, you can contact us and we will actively find a suitable solution. No communication and leaving the neutral or negative feedback may not advisable and cannot solve any problems. Welcome! We wish you a happy shopping here!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	JINGYAN
Country of Manufacture	China
Model	MESR-100
